AVMatrix SD1141 1×4 SDI Re-Clocking Distribution Amplifier
Model: SD1141
About: AVMatrix SD1141 1×4 SDI Re-Clocking Distribution Amplifier
The SD1141 is a miniature, low-cost 1×4 3G HD-SDI/HD-SDI/SDI re-clocking distribution amplifier. Featuring four separately buffered SDI outputs, the SD1141 provides automatic input detection, re-clocking and cable equalization.
Features
- Automatically detects SD, HD and 3G-SDI
- 4 buffered and re-clocked outputs
- 3G/HD/SD-SDI multi-rate signal processing
- Output 2 & 4 support DVB-ASI signal
- Automatic cable equalization and signal retiming
- Pass all ancillary data and embedded audio
- Micro USB and DC power
- Detachable bracket design for wall mounting
UPC: 6971118000074
