SmallHD Indie 5 Monitor

About: SmallHD Indie 5 Monitor

Indie 5 is the smallest and lightest monitor in the Smart 5 Series, with optional camera-control functionality, all your favorite PageOS 5 tools, and customization on a premium touchscreen 5-inch monitor. At 1000nit brightness, this compact model is also daylight-viewable.

Indie 5’s hyper-responsive touchscreen display, with 1080p resolution, is backed by PageOS 5. With Indie 5, you’ll be able to access our intuitive UI/UX for at-a-glance adjustments and effortless navigation, integrated tools for more accurate exposure and color control, Look-Around Camera Control, EL Zone, Advanced Teradek RT overlays, and so much more.

Indie 5 is our entry-level Smart 5 monitor, ideal for professionals on an indie budget.

Camera Control for RED DSMC2 & RCP2

Transform your touchscreen into the central command hub of your camera. SmallHD’s proprietary software enables unfettered access to RED DSMC2,KOMODO, and V-RAPTOR camera functions and project settings such as Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more. *Individual Camera Control software licenses are sold separately.

Next-Gen Tools, Customizable Workflow, Premium UX

Smarter, more intuitive software tools for at-a-glance adjustments, effortless navigation, and more accurate exposure and color control. Personalized Page Profile, Focus and Exposure Assist, Lookaround Camera Control, Tetrahedral LUT Interpolation, Advanced Teradek RT Overlays, and much, much more.

LOOK-AROUND CAMERA CONTROL - Camera Interface On Every Page

View and adjust crucial camera-control functions and PageOS 5 tools at the same time on Smart 5 Series Monitors with a camera-control interface anchored to every page.

TERADEK RT OVERLAYS - Lens Control Overlays

View critical lens, focus, iris, and zoom data on yourmonitor. Quickly create, edit, and delete visual marks on the focus scale, set on-screen limits, and even pinch-zoom the scale for extremely precise focal-change sequences.

EL ZONE - Light Metering Evolved

Developed by legendary cinematographer, Ed Lachman, ASC, EL Zone is a stop-based exposure map tool that works like a virtual spot meter, replacing IRE exposure values with stops. Sensor data from the camera provides a reference point, and a false color represents each stop above and below 18% gray, allowing for easier, more intuitive on-set communication.

TOUCH FUNCTION BUTTONS - Customizable On-Screen Shortcuts

Smart 5 has easily accessible on-screen Touch Function Buttons. Assign workflow shortcuts for software tools, input switching, display brightness, and more.

HORIZON INDICATOR - Keep Your Frame on the Level

A built-in digital bubble-level overlay you can apply to the image to precisely gauge camera rotation.

Specifications

• Environmental
  • Mount Points -  6x 1/4-20 Mounting Points
• Display
  • Panel Type -  Touch-Screen
  • Resolution -  1920 x 1080
  • Aspect Ratio -  16:9
  • Brightness -  1000nits
  • Backlight Type -  Edgelit
• Input Signal
  • 3G-SDI Input Types -  1x 3G-SDI
• Output Signal
  • HDMI Output Types -  1x HDMI 2.0 (4Kp30)
• Connector Type
  • SDI -  1x 3G-SDI (In), 1x 3G-SDI (In/Out)
  • HDMI -  1x HDMI 2.0 (4Kp30) [In], 1x HDMI 2.0 (4Kp30) [Out]
  • Audio -  1x 3.5mm Stereo Headphone Jack
• Data I/O
  • Storage Media -  1x SD Card Slot
  • USB -  1x Micro USB
• Power
  • Input -  Barrel Power Input
• Software
  • Pixel Zoom -  Yes
  • Focus Assist -  Yes
  • Peaking -  Yes
  • False Color -  Customizable False Color Overlays
  • Waveform -  Customizable 4K Waveform w/Region of Interest Highlighting (Coming Soon)
  • Custom LUTS -  17pt 3D-LUT on Output/Input 33pt 3D-LUT on Output/Input
• Camera Control
  • Camera Control Compatibility -  COMING SOON: Camera Control for RED DSMC2 Camera Control for RED RCP2 Cameras (KOMODO, DSMC3)
    • *Additional camera control compatibility coming soon
• Compare Chart
  • Resolution -  1920 x 1080
  • Color Depth -  10-Bit Color Intelligence Engine
  • Brightness -  1000nits
  • SDI (1080p60) -  1x 3G-SDI Input 1x 3G-SDI (I/O)
  • HDMI (4Kp30) -  1x HDMI 2.0 Input 1x HDMI 2.0 Output
  • Touchscreen -  YES
  • Joystick Control -  NO
  • Physical Buttons -  NO
  • Power Input -  2.0mm Barrel
Power Input
  • Locking USB Control Port -  NO
  • Ethernet Port -  NO
  • Camera Control Compatibility* -  Coming Soon
  • Battery Support -  Integrated Sony L-Series
  • Touchscreen Lock -  YES
  • Built-in Teradek Bolt 6 -  NO
