Lilliput RM7026-12G Dual 7in 3RU Rackmount 12G SDI Monitor
Model: RM7026-12G
About: Lilliput RM7026-12G Dual 7in 3RU Rackmount 12G SDI Monitor
The RM7026-12G is a High Brightness, High Quality Dual Panel Monitor which supports HDMI 2.0 and 12G SDI input and output. Sporting dual 7″ 1000 nits high brightness LTPS screens, the unit has support for up to 2160p (4K) at 60Hz and can monitor 2 independent input sources, which makes it ideal for installation into broadcast mixing rooms or Outside Broadcast vehicles.
Video can be looped in and out of the RM-7026, and it can also be controlled by a connected computer, which will allow you to run the monitor independently and as a part of an integrated video production workflow.
- Screen Size: 7 inches
- Resolution: 1920x1200
- Aspect Ratio: 16:10
- Housing Material: Metal
- Brightness: 1000 nits
- Inputs: HDMI 2.0, 12G-SDI, Tally, LAN,
Specifications​
- Display
- Size - Dual 7″
- Resolution - 1920×1200
- Brightness - 1000cd/m²
- Aspect ratio - 16:10
- Contrast - 1200:1
- Viewing Angle - 160°/160°(H/V)
- HDR Support - HLG / ST2084 300 / 1000 / 10000
- Video Input
- SDI - 2×12G (supports up to 4K 60Hz)
- HDMI - 2×HDMI (supports up to 4K 60Hz)
- LAN - 1
- Video Loop Output
- SDI - 2×12G (supports up to 4K 60Hz)
- HDMI - 2×HDMI 2.0 (supports up to 4K 60Hz)
- Supported In / Out Formats
- SDI - 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50, 720p 60/50…
- HDMI - 2160p 60/50/30/25/24, 1080p 60/50/30/25/24, 1080i 60/50, 720p 60/50…
- Audio In/Out
- Speaker - -
- Ear Phone Slot - 3.5mm
- Power
- Input Voltage - DC 12-24V
- Power Consumption - <=21W (12V)
- Environment
- Operating Temperature - 0°c to 50 °c
- Storage Temperature - -20° to 60°c
- Size
- Dimensions (LxWxD) - 18.9 x 5.18 x 1.28 inch (480 x 131.6 x 32.5)
- Weight - 4.03 lbs (1.83kg)
UPC: 6950821602737
Reviews: Lilliput RM7026-12G Dual 7in 3RU Rackmount 12G SDI Monitor
Warranty: Lilliput RM7026-12G Dual 7in 3RU Rackmount 12G SDI Monitor
AVShop.ca Warranty:
30 Days
Manufacturer's Warranty:
1 Year Limited Warranty
Manufacturer's Warranty will cover parts, labour and return shipping back to you once repaired. Shipping into the service centre is not covered
For Quebec Residents - Disclosure under the Consumer Protection Act
In compliance with Bill 29, AVShop.ca and Lilliput do not guarantee the availability of replacement parts, repair services, or maintenance information for any products. Any applicable manufacturer warranties will remain in place.
