Lilliput PVM220S-E 21.5" 1000-Nits Live Stream & Recording Monitor (Gold Mount)
Model: PVM220S-E-ABBP
About: Lilliput PVM220S-E 21.5" 1000-Nits Live Stream & Recording Monitor (Gold Mount)
The LILLIPUT PVM220S-E is a professional high brightness live streaming and recording monitor, packed with features and facilities for the professional photographer, videographer, or director. Compatible with a multitude of inputs – and featuring the option of a 3G SDI and HDMI 2.0 input connection for live streaming quality monitoring. As a recording product, it can also record the current HDMI or SDI video signal and save it to the SD card. The recorded video supports up to 1080p signal format.
Specifications
- Display
- Brightness - 1000 cd/m²
- Contrast Ratio 1000:1
- Resolution 1920 x 1080
- Technology Calibration to Rec.709 with optional calibration unit
- Viewing Angle 178°/178°（H/V)
- HDR ST2084 300/1000/10000/HLG
- LUT Support 3D LUT (.cube format)
- Screen Size 21.5"
- Supported Log Formats SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User…
- Supported Formats
- HDMI Formats Supported - 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60…
- Monitor Specification
- Video Inputs - SDI 1×3G, 1X HDMI 2.0
- Video Outputs - 1×3G, 1X HDMI 2.0, LAN - 1×1000M (PoE is optional)
- Audio In / Out (48 kHz PCM Audio)
- Built In Speakers - 1
- Ear Jack - 1x 3.5mm
- HDMI Audio Frequency - 8ch 24-bit
- SDI Audio Frequency - 2ch 48kHz 24-bit
- Recording
- Video Resolution - 1920×1080 / 1280×720 / 720×480
- Frame Rates - 60 / 50 / 30 / 25 / 24
- Codecs Supported - H.264
- Audio Supported Rates - 44.1kHz / 48kHz
- Storage (Recording) - SD Card - supports up to 512GB
- Split Recording File Intervals - 1min / 5 mins / 10 mins / 20 mins / 30 mins / 60mins
- Size
- Dimensions - 20 x 12.64 x 1.85 in (508 × 321 × 47 mm)
- Weight - 10.47 lbs (4.75 kg)
- Power
- Compatible Batteries - Anton Bauer Mount
- Input Voltage - DC 9-24V, Battery 14.8V Nominal
- Power Consumption - ≤53W (DC 15V / Optional PoE PD function, supports IEEE802.3 bt protocol)
- Environment
- Operating Temperature - 0℃~50℃
- Storage Temperature - -20℃~60℃
