AVMatrix Eagle T10 4K 10X Zoom TOF Autofocus Live Stream Camera

About: AVMatrix Eagle T10 4K 10X Zoom TOF Autofocus Live Stream Camera

The Eagle T10-4K is a 4K sensor camera with a Time Of Flight Ranging sensor built in, designed for use was a fixed-point camera for Streaming, Podcasting, or any host of other in-situ applications. To suit the needs of a streamer, the camera has both an HDMI and USB-C output, so the video feed can be used with both an off-camera confidence monitor, and the footage can be sent through to a host PC running OBS, Teams, or similar software.

• HDMI & USB Type-C output up to 4K 30Hz - for high quality, high definition outputs
• 10X Optical Zoom Lens
• Fast accurate autofocus with ToF ranging technology
• High quality 1/2.8” 8M CMOS Sensor
• Capture support YUY2 and MJPG
• Audio input and RS485 serial control
• Auto focus/exposure/white balance
• A variety of preset styles: meeting, beauty, jewel, fashion, custom
• Landscape and portrait installation, Image mirror and flip
• Control with menu buttons & IR remote control
• Aluminum alloy body with excellent heat dissipation for 24/7 operation

Specifications

• SENSOR
  • Sensor: 1/2.8" 8MP CMOS Sensor
  • Max Frame Rate: 3840Hx2160V@30fps
• LENS​
  • Optical Zoom: 10X
  • Focusing Mode: ToF Auto Focus & Digital Focus
  • Focal Length: F=4.32~40.9mm
  • Aperture Value: F1.76~F3.0
  • Focus Distance: Wide: 30cm, Tele: 150cm
  • Field of View: 75.4°(Max)
• INTERFACES
  • Video Output: HDMI, USB(UVC)
  • USB Capture Format
    • MJPG 30P: 3840x2160
    • MJPG 60P: 1920x1080/1280x960/1280x720/1024x768/800x600/720x576/640x480
    • YUY2 60P: 1920x1080/1280x960/1280x720/1024x768/800x600/720x576/640×480
  • HDMI Format: 2160p 30, 1080p/720p 60/50/30/25
  • Audio Input: 3.5mm Audio In
  • Control Port: RS485 Serial (Support protocol VISCA)
• FUNCTIONS
  • Exposure Mode: AE/ AE Lock/ Custom
  • White Balance Mode: AWB/ AWB Lock/ Custom/ VAR
  • Focus Mode: AF/ AF Lock/ Manual
  • Preset Image Styles: Meeting/ Beauty/ Jewel/ Fashion/ Custom
  • Control Methods: IR Remote Control & Buttons
  • Backlight Compensation: Support
  • Anti-Flicker: 50Hz/ 60Hz
  • Noise Reduction: 2D NR & 3D NR
  • Video Adjustment: Sharpness, Contrast, Color Saturation, Brightness, Hue, Color Temp, Gamma
  • Image Flip: H Flip, V Flip, H&V Flip
• OTHERS
  • Power Consumption: <5W
  • USB Power Voltage Range: 5V±5% (4.75~5.25V)
  • Operation Temperature Range: 0-40℃
  • Installation Methods: Landscape & Portrait Orientation
• Dimension (LxWxD) - 3.07 x 3.07 x 6.08 inch (78 x 78 x 154.5mm)
• Weight
  • Net weight: 1.51 lbs (686.7 g)
  • Gross weight: 2.35 lbs (1064 g)
