AIDA HD-100A Full HD HDMI Camera
Model: HD-100A
About: AIDA HD-100A Full HD HDMI Camera
The AIDA HD-100A is a cost-friendly Full-HD Broadcast Camera designed for any level of production. Packed with a 1/3″ progressive CMOS image sensor and interchangeable lens, the HD-100A provides clear, crisp HD video suitable for any existing workflow. The HD-100A offers versatile Full-HD resolutions including drop-frames, adjustable video settings, and a small rugged form factor, making it perfect anywhere you need it to be.
MAIN FEATURES
- Full HD Progressive Scan sensor captures sharp and vivid color under different light conditions.
- Advanced digital image processor provides vivid and detailed images by utilizing WDR, White Balance, and Noise Reduction.
- Motion-compensated temporal noise reduction filter leads to effective noise reduction for motion video without blur.
- HDMI seamless video performance.
- Compatible with other industry leading products, conforming with SMPTE 424M/292M standard.
- Black Level Set-up provides the better color transition from digital to analog.
- Auto White Balance and shutter speed provides the optimized performance in a variety of situations.
- Interchangeable lens design makes it compatible with auto-iris CS and C mount lenses.
- Built-in OSD controls for customizable image settings.
- Versatile, compact, and rugged design.
- With TRS Stereo Audio Input for embedded audio over HDMI.
Video
- Image Sensor 1/3 inch Progressive CMOS
- Sensor Size 5.346mm x 3.003mm (16:9)
- Effective Pixels Horizontal: 1920, Vertical: 1080
- Pixel Size 2.75 µm x 2.75 µm
- Resolution 1080p & 1080i: 1920 x 1080
- 720p & 720i: 1280 x 720
- Resolution/Rate 1080 60p/59.94p/50p/30p/29.97p/ 25p
- 1080 60i/59.94i/50i
- 720 60p/59.94p/50p/30p/25p
- Output HDMI 1.3a
- Color Space 4:2:2 (YCbCr) 10bit
- Min. Illumination 0.2Lux (Day), 0.1Lux (Night), 0.005Lux (Slow Shutter ON)
- White Balance Auto & Manual (9,000 K - 11,000 K)
Lens
- Lens C/CS Mount (Default 4mm HD Lens)
Audio
- Input 3.5mm TRS Stereo Mic-in & Line in over I/O Cable
- Sample Rate 16/24/32 Bits
Physical
- Camera Control RS-485, OSD Button
- Operation Temp 32° F - 104° F
- Dimension 49mm x 49m x 71mm / 1.92” x 1.92” x 2.79” (With default 4mm Lens)
- Weight 180g / 0.39lbs (With default 4mm Lens)
- Power 6W at 12VDC (+9 - +15VDC)
