Glensound GS-MIX011 6 Input Mixer x 2 With Limiters On All Inputs & Outputs
Model: GS-MIX011
About: Glensound GS-MIX011 6 Input Mixer x 2 With Limiters On All Inputs & Outputs
Glensound GS-MIX011 is a dual 6-input line-level audio mixer housed in a 1U rackmount chassis, designed for professional broadcasting, internet streaming, and live production environments. With compressor/limiter circuits on every input and output, it provides smooth, consistent audio mixes even when handling unpredictable or varied signal levels.
Features
- Two independent mixers, each with 6 line-level inputs
- Electronically balanced inputs and outputs for professional audio interfacing
- Independent rotary gain controls per input (±20 dB)
- Built-in compressor/limiter on all inputs and outputs to prevent clipping
- LED indicators show limiter activity on each channel
- Dual outputs per mixer for routing flexibility
- Output gain adjustable ±10 dB (or +10 to -∞ dB via internal jumper)
- Simple front panel layout for intuitive use
- Ideal for managing level variation in sources like referee mics, FX returns, or feeds from other venues
Specifications
| Inputs | 12 total (6 per mixer), electronically balanced, >30kΩ impedance |
|---|---|
| Outputs | 4 total (2 per mixer), electronically balanced, ≤50Ω impedance |
| Input Gain | ±20 dB via front panel rotary control |
| Output Gain | ±10 dB (or +10 to -∞ dB with internal jumper) |
| Input Limiter Threshold | 0 dBu (LED illuminates at +8 dBu) |
| Output Limiter Threshold | +4 dBu (LED illuminates at +8 dBu) |
| Noise Floor | -80 dBu (min gain), -78 dBu (line-up), -70 dBu (max gain), 22 Hz – 22 kHz RMS |
| Power Supply | Internal switch-mode PSU, 100–250 VAC |
| Power Consumption | 5.12 Watts |
| Dimensions | 1U 19" rackmount, 257 mm deep (excluding connectors) |
| Weight | 1.94 kg |
