Audio Technica ATW-T1407 System 20 PRO Desk Stand Transmitter

About: Audio Technica ATW-T1407 System 20 PRO Desk Stand Transmitter

ATW-T1407 System 20 PRO desk stand transmitter.

• 3-pin XLR-F gooseneck microphone connector (compatible with quick-mount gooseneck microphones, sold separately)
• Long-lasting internal lithium-ion batteries for all-day transmitter use
• Selectable mute operation (toggle, touch-to-talk, or touch-to-mute)
• Two LED options: standard mode and conference mode
• OLED display
• USB Type-C connector for charging (transmitter can be used while charging)

Specifications

• Overall System
  • Operating Frequencies - 2,402～2,480MHz
  • Dynamic Range - 120dB (A-weighted), typical
  • Total Harmonic Distortion - < 0.05%, typical
  • Operating Range - 60m (open environment w/ no interfering signals)
  • Maximum Simultaneous Use (recommended)
    • Standard: 10 channels
    • HD mode: 20 channels
      • It depends on the region and environment.
  • System Frequency Response - 20 to 20,000Hz
    • Varies depending on the microphone to be installed.
  • Delay
    • Standard: 2.8ms
    • HD mode: 6.7ms
  • Audio Sampling Rate
    • Standard: 24bit/48kHz
    • HD mode: 24bit/48kHz
  • Encryption Method - AES128
• ATW-T1407 Desk Stand Transmitter
  • Modulation mode - GFSK
  • RF output - 10mW EIRP
  • RF sensitivity - -90dBm, typical
  • Whip antenna - True diversity
  • Microphone Type - Supports gooseneck microphones
  • Phantom power supply - DC24V
  • Operating temperature - 5ºC to +40ºC
  • Built-in battery - 3.7V lithium-ion battery (5.5Wh, 1460mAh)
  • Battery Life
    • When using gooseneck microphone without LED: Approx. 12 hours
    • When using gooseneck microphone with LED: Approx. 8 hours
  • Charging time - Approx. 3 hours and 10 minutes
  • USB Charging Port - USB Type-C (USB 2.0)
  • Dimensions - 90.5mm x 129.4mm x 47.6mm (W x D x H)
  • Weight - 490g (including battery)
  • Included accessory
    • USB power adapter
    • Blade tip for USB power adapter
    • USB cable (1.5 m)
