Allen & Heath AHM-32 32x32 Audio Matrix Processor
Model: AHM-32
About: Allen & Heath AHM-32 32x32 Audio Matrix Processor
With 32 zone outputs, echo cancelling and audio networking options, AHM-32 is ideal for multi-room installations in hospitality, corporate and education environments.
- 32x32 processing matrix
- 12x12 local analogue I/O
- I/O Port for audio networking, up to 128x128
- Dante 96kHz option card (AES67 and DDM ready)
- SLink 128x128 option card for audio expansion
- 32 configurable processing outputs – mono / stereo zones or speaker processing
- 96kHz FPGA core with ultra-low latency
- Front panel screen and navigation
- 8x SoftKeys
- Compatible with IP1, IP6, IP8 remote controllers
- 2x2 local GPIO plus networkable GPIO interface
- TCP/IP protocol for third party integration
- Crestron, AMX and Extron drivers
- Mac / Windows System Manager software
- Custom Control app and editor for BYOD
- 16 user profiles
- Integrated stereo playback
- Event scheduler
ALWAYS IN CONTROL
In addition to remote controllers, GPIO and 3rd party integration, AHM-32 has a front panel screen and 8x programmable SoftKeys for intuitive volume control, source select, preset recall and more.
ACOUSTIC ECHO CANCELLATION
The Acoustic Echo Cancellation (AEC) module for AHM-32 provides 12 channels of AEC and is designed for teleconferencing and videoconferencing scenarios.
SOUND MANAGEMENT
- 4x Automatic Mic Mixers
- ANC (Ambient Noise Compensation)
- Priority Ducking
- 8-band PEQ, dynamics and delay on every input and zone
- Speaker processing with x-over filter, delay, limiter and PEQ
UPC: 6938122252127
Reviews: Allen & Heath AHM-32 32x32 Audio Matrix Processor
Warranty: Allen & Heath AHM-32 32x32 Audio Matrix Processor
AVShop.ca Warranty:
30 Days
Manufacturer's Warranty:
Limited One Year Warranty on most products. See user manual for details.
Manufacturer's Warranty will cover parts, labour and return shipping back to you once repaired. Shipping into the service centre is not covered
