Appsys ADX-8 ADAT Over Cat5 Extender
Model: ADX-8
About: Appsys ADX-8 ADAT Over Cat5 Extender
Without any kind of compression or other potentially sound-degrading conversions, the input signal is 100% bitwise transmitted in real time to the output. Ideally suited for connecting your PC to your HiFi equipment, for upgrading your network cabling to a true HiFi-capable sound bridge, or to listen to music in uncompromising quality anywhere you can reach with standard network cabling. Or use the extender in your recording studio to overcome the 5 meter length limit of ADAT connections!
Features
Lossless, uncompressed 1:1 transmission
Standard TOSLINK optical jacks at input and output
Eliminates hum, buzz and noise thanks to galvanic isolation (ground loop removal)
Near-zero latency (<1µs)
Compatible with all digital audio formats (ADAT Lightpipe, SPDIF, AC-3 (Dolby Digital ), DTS etc.)
up to 96 kHz sample rate / 12.5 MBit signalling rate
Cost-effective installation using standard Cat5 network cabling
Quality product "Made in Switzerland"
Specifications
- Input/Outputs
- Optical connector
- F05 Type TOSLINK compatible
- Maximum distance between sender and receiver - 100 m (328 ft.)
- Supported audio formats
- ADAT Lightpipe
- S/PDIF (up to 96kHz / 24 bit)
- Dolby Digital 5.1 (AC-3)
- DTS
- all other TOSLINK compatible formats up to 13.2 MBit/s (NRZ-encoding)
- Pinout Cat5 cable
- (orange/white) DATA+
- (orange) DATA–
- (green/white) NC
- (blue/white) +12V
- (blue) +12V
- (green) NC
- (brown/white) GND
- (brown) GND
- Power Supply
- 9-15V DC 100mA, Polarity: Center Positive
- Plug: ID=2.5mm OD=5mm Length=9mm
What's Included
- Transmitter (TOSLINK->Cat5 Cable adapter)
- Receiver (Cat5 cable->TOSLINK adapter)
- AC adapter in "green" switching technology
- Printed manual
