Glensound VITA BB PLUS Dante/ AES67 Announcers Box

About: Glensound VITA BB PLUS Dante/ AES67 Announcers Box

Glensound VITA BB PLUS is a robust Dante®/AES67 network audio interface designed for single-user commentary applications. Encased in a traditional desktop format, it offers a mic/line input and comprehensive headphone monitoring, encompassing two 4-wire circuits typically utilized for on-air and talkback channels. The high-quality microphone input, integrated with Glensound's Referee compressor, ensures suitability for live broadcasts, such as small outside broadcasts or off-tube commentary booths.

Features

• Complete Commentary Functionality: Provides full commentary features and 4-wire integration in a desktop design.
• Large Format Illuminated Front Panel Switches: Equipped with big buttons for easy operation, enhancing user experience during live broadcasts.
• Dante®/AES67 AoIP Network Compatibility: Seamlessly integrates with Dante® or AES67 networks for flexible audio-over-IP connectivity.
• Versatile Input Options: Input is switchable between line, mic, or mic with +48V phantom power, accommodating various audio sources.
• High-Quality Microphone Amplifier: Features a low noise, high headroom mic amplifier for superior audio performance.
• Advanced A/D Conversion: Utilizes a 48kHz 24-bit A/D converter to ensure high-fidelity audio conversion.
• Comprehensive Headphone Monitoring: Provides a headphone output on a 6.35mm jack socket with two inputs for monitoring from the network audio connection, each with adjustable levels and left/both/right channel switching.
• Flexible Output Options: Two outputs are available—one dedicated to main program audio and another for the talkback circuit, both accessible via a single RJ45/CAT5 network audio connection.
• Configurable Push Buttons: Independently configurable buttons for both outputs using Config+, supporting latching, momentary, or lazy modes to suit different operational needs.
• Intelligent Headphone Amplifier: Capable of delivering correct output levels into both low and high impedance headphones, and can correctly drive mono earpieces with mono jack plugs.
• Power Over Ethernet (PoE): Powered via PoE for convenient and efficient operation.

Specifications

Included Accessories

• IEC power cable for mains connection (if applicable).
• User manual with configuration guidelines.
