ChamSys QuickQ Rack+ Lighting Control Console

About: ChamSys QuickQ Rack+ Lighting Control Console

QuickQ Rack+ is a small rack mountable version of the QuickQ console designed for installations. It features the same operating system as QuickQ series consoles, but is designed to operate as a remote system outputting six universes of control via direct DMX or Art-Net/sACN, without physical user control.

• 6 Universe output via Art-Net/sACN
• 2 RDM-Enabled DMX Outputs
• User Interface Modelled on smartphone icon interfaces for ease of use
• In-Built Wi-Fi for easy connection to the remote app on iOS & Android devices
• Intuitive interface allowing simple control of all fixture attributes
• Dual Network ports allowing separation of Lighting and Control Data

Featuring 10 playback/execute buttons on the unit, the QuickQ Rack is ideally paired with 10Scene wall plates. The unit can be used as a desktop box or rack mounted with the supplied rack ears.

Dual network ports enable the separation of lighting and control data. The console’s two RDM-enabled DMX ports enable automatic detection and patching of RDM compliant fixtures, and its internal Wi-Fi antenna enables remote connection to the free QuickQ app available on iOS, Android and Windows tablets and phones

Specifications

• Hardware
  • Rack Size: 1U
  • Universes supported: 6
  • Direct DMX Outputs 5-Pin XLR: 2
  • 10Scene Buttons: 10
  • 10Scene Ports: 4
  • External Monitor: 1920 x 1080 HDMI
  • Inbuilt Wi-Fi: Yes
  • Network Port: 2
  • USB Ports: 2
  • Audio Input: 1
  • Audio Output: 1
  • MIDI Ports in/out: Yes
  • Power Input: TrueCon Power Input: 90-250v AC
  • Max Power Consumption (mains): 60w
• Software
  • Max Number of DMX Channels: 3072
  • Max Number of Fixtures Supported: 3072
  • Max Number of Cue Stacks: 2000
  • Max Number of Chases: 2000
  • Max Number of 10Scene Zones: 10
  • Midi & Midi Timecode Supported: Yes
  • OSC Supported: Yes
  • RDM Autopatch for fast show patching
  • Fixture library of over 60,000 fixture files
  • Built in FX generator
  • Colour picker and Gel inbuilt Gel library
  • Offline designer software available for Windows and Mac
  • Simple Hot-Takeover mode allowing an external console to take control
• Physical
  • Dimensions (WxDxH): 15.8 x 7.7 x 1.77 inch (403 x 195 x 45mm)
  • Weight: 6.8 lb (3.1kg)

What's Included

• 2x Rack Ears
• 4x 10Scene Connectors
• 1x True1 power cable
