Datavideo NVD-30 MKII HDMI IP Video Decoder
Model: NVD-30MKII
About: Datavideo NVD-30 MKII HDMI IP Video Decoder
Decodes all common streaming protocols
Decode videos from Datavideo encoders, Youtube Live, UStream, and other major CDNs. The NVD-30 MARK II decodes all common streaming protocols, directly from YouTube Live, UStream, Dailymotion, Livestream, Twitch and other major CDNs, and skips all third-party ads.
Decodes all common streaming protocols including SRT
The NVD-30 MARK II decodes common streaming protocols including SRT, RTSP, RTMP, UDP, TCP, HTTP, HLS and MPEG-TS. The SRT streaming protocol now features security, reliability, and low latency, enabling high quality video streaming with ultra-low latency even in unstable network environments.
Output high quality video at 1080p 50/60 FPS
The NVD-30 MARK II IP Video Decoder supports HDMI and Composite video output with resolutions up to 1080p 50/60 FPS. RCA audio output is also supported.
Easily connect encoders to decoders with dvCloud
The NVD-30 MARK II Decoder is seamlessly compatible with our dvCloud live streaming platform, when connected to dvCloud you can remotely control the decoder from anywhere in the world.
- Connect encoders to decoders anywhere in the world without firewall configuration,
- Connect encoders to decoder with a single click, no need to copy stream URLS or IP addresses.
- Connect multiple decoders to a single encoder without putting extra load on the internet connection at the encoder side. The video encoder sends a single stream to the cloud and the cloud distributes it to the multiple decoders via its high-speed connection to the internet backbone.
- Remotely monitor and control all connected decoders from a single dashboard,
- Detailed statistics allow you to make sure that every frame makes it all the way from encoder to decoder.
Perfectly Matched with Datavideo Webcast Encoders
The NVD-30 MARK II can be matched with Datavideo NVS-33/34/40 and other webcast encoders to create a Full HD video transmission architecture based on Ethernet, WiFi or the Internet.
Real-time Video Flip and Rotate
The NVD-30 MARK II adds real-time video flipping and rotating functions for more flexible video output options.
RMC-12 Remote Control
RMC-12 remote control is included for more convenient operation.
Specifications
- Audio/Video Input
- Stream Input
- RTSP over UDP (Unicast / Multicast)
- RTSP over TCP
- RTSP over HTTP
- SRT (Secure Reliable Transport) caller
- MPEG-TS over UDP
- RTMP Pull
- RTMP Push (Internal Server)
- UDP raw (Unicast/Multicast)
- HLS over HTTP
- MPEG-TS over TCP Pull
- Video sharing websites
- Stream Input
- Audio Output
- 2x RCA(L/R)
- HDMI embedded audio
- Video Output
- Composite (analogue)
- HDMI (digital)
- Network Feature - 1x RJ-45 Female (10/100M Ethernet) DHCP/Static IP
- Supported Video Resolution
- 1080p 60/59.94/30/29.97/25/24
- 1080i 60/59.94/50
- 720p 60/59.94/50
- 576i 50 (PAL)
- 480i 60 (NTSC)
- Supported Decoding Resolution - Up to 1080p60/50
- Control
- Web browser UI for configuration and control.
- TCP/IP Socket commands
- Update - Automatic firmware upgrade
- Power
- Input AC 100~240V Switching Adaptor
- Output DC 12V / 0.5 A
- Environmental Conditions
- Operating temperature: 0~40°C,
- Storage temperature: -10~60°C
- Dimension (LxWxH) - 8.66 x 5.63 x 1.85 in (220 x 143 x 47 mm)
- Weight - 2.2 lb (1 kg)
- Power - DC 12V, 0.5A
What's in the Box
- 1x NVD-30 MARK II product
- 1x AD Switch DC 12V
- 1x Remote Control
