Aputure Spotlight Max 50 Degree Lens
Model: APXF043A35
About: Aputure Spotlight Max 50 Degree Lens
The Spotlight Max 50° Lens is a wide-angle projection spotlight lens designed to be used with the Spotlight Max.
With custom precision optics, the Spotlight Max 50° Lens efficiently concentrates and blends light into a single wide and clean beam while
maintaining its light source’s color accuracy and mitigating chromatic aberration. In addition, the 50° Lens intensifies its light engine’s output and increases the throw of the fixture, allowing subjects to be illuminated from far distances.
The use of telecentric optical elements in the 50° Lens and the Spotlight Max ensures that the difference of the output field angle and beam angle are minimized, resulting in an illumination circle with even edge-to-edge light distribution without hotspots.
The Spotlight Max 50° Lens comes in a protective soft carrying case, making transportation and storage a breeze.
Features
- 50° Wide-Angle Projector Lens for Spotlight Max
- Optimized for High-Powered LED Fixtures
- Custom Precision Optics With Minimal Chromatic Aberration and Color Shift
- Efficient Light-Blending Optical Design for Compatibility with Full- Color Fixtures
- Telecentric Element Groups for Even Edge-to-Edge Light Distribution and Minimal Distortion of Illumination Circle
- Durable All-Metal Build
- Included Protective Soft Case
Specifications
- Spotlight Max 50° Lens Photometrics
- LS 600d Pro
- 3m
- 5600K - 2710 lux / 201 fc
- 3200K - -
- 5m
- 5600K - 976 lux / 75 fc
- 3200K - -
- 7m
- 5600K - 433 lux / 40 fc
- 3200K - -
- 3m
- LS 600x Pro
- 3m
- 5600K - 1939 lux / 180 fc
- 3200K - 1451 lux / 135 fc
- 5m
- 5600K - 698 lux / 65 fc
- 3200K - 522 lux / 49 fc
- 7m
- 5600K - 356 lux / 33 fc
- 3200K - 266 lux / 25 fc
- 3m
- LS 600c Pro
- 3m
- 5600K - 1207 lux / 112 fc
- 3200K - 948 lux / 88 fc
- 5m
- 5600K - 434 lux / 40 fc
- 3200K - 341 lux / 32 fc
- 7m
- 5600K - 525 lux / 49 fc
- 3200K - 174 lux / 14 fc
- 3m
- LS 1200d Pro
- 3m
- 5600K - 4233 lux / 393 fc
- 3200K - -
- 5m
- 5600K - 1524 lux / 142 fc
- 3200K - -
- 7m
- 5600K - 778 lux / 72 fc
- 3200K - -
- 3m
- LS 600d Pro
- Dimensions - 8.1 x 7.8 x 9.72 in (20.5 x 19.9 x 24.7 cm)
- Weight - 8.64 lbs (3.92kg)
What’s in the Box
- Spotlight Max 50° Lens
- Carrying Case
UPC: 6971842186761
