CyberPower PFC Sinewave 1U Rackmount UPS System - 700VA / 400W
Model: CP700PFCRM1U
About: CyberPower PFC Sinewave 1U Rackmount UPS System - 700VA / 400W
The CP700PFCRM1U is a PFC Sinewave rackmount UPS that provides battery backup (using sine wave output), surge protection, and EMI/RFI filtration for security systems, audio/visual equipment, and networking equipment requiring active PFC power source compatibility.
The CP700PFCRM1U features Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power, and a multifunction control panel with a color LCD to quickly confirm status and alerts at-a-glance. Remote management and/or monitoring is available with optional purchase of a Remote Network Management Card or Cloud Monitoring Card. At only 9.04 inches in depth, the CP700PFCRM1U fits comfortably in short-depth rack installations where space is at a premium.
The CP700PFCRM1U comes with a three-year warranty (including coverage of batteries) and a $300,000 Connected Equipment Guarantee.
Features
- Battery Backup - Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
- Surge Protection - Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
- Sine Wave Output - Generates energy that is identical to, or cleaner than the utility company’s power grid. Benefits include low total harmonic distortion, minimal electrical noise, and optimal line clarity.
- Short Depth Rackmount - Fits comfortably in racks as small as 14 inches in depth, which is ideal for situations where space is at a premium.
- EMI/RFI Noise Filter - Maintains clean power for connected equipment by filtering out electromagnetic and radio frequency interference to improve picture and sound quality.
- Multifunction LCD Panel with Color Display - Displays immediate, detailed information on the UPS battery and power conditions. The color display quickly alerts users to potential problems before they can affect critical equipment and cause downtime.
- Automatic Voltage Regulation (AVR) - Conserves battery life by increasing the AC power and maintaining a safe voltage level without switching to battery mode.
- Data Line Protection - Prevents power surges that travel through Ethernet lines from causing damage to electronics.
- Line Interactive Topology - Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
- ENERGY STAR - This model is an ENERGY STAR certified Uninterruptible Power Supply (UPS) system. ENERGY STAR is the trusted, government-backed symbol for energy-efficient products and practices that help save money and protect the environment.
- GreenPower UPS Bypass Design - A patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.
- Ultra Quiet Design - Minimizes noise during operation for a quieter work environment.
- PowerPanel Business Software - Provides IT professionals with tools for monitoring and managing the UPS and backup power. This software offers remote management functionality. (Free software download available)
- Three-Year Warranty - CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.
- Connected Equipment Guarantee - CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
Typical Applications
- Automatic Voltage Regulation
- Corporate Servers
- Department Servers
- Network Devices
- Telecom Installations
- Workstations
Specifications
- General
- Energy Saving - GreenPower UPS Bypass Technology
- Energy Star Certified - Yes
- UPS Topology - Line Interactive
- Battery
- Battery Quantity - 2
- Battery Size - 6 V / 7 Ah
- Battery Type - Sealed Lead-Acid Battery
- Hot Swappable - Yes
- Replacement Battery Cartridge - RB0690X2
- Replacement Battery Cartridge Quantity - 1
- Runtime at Full Load - 1.5 min
- Runtime at Half Load - 10.5 min
- Typical Recharge Time - 8 Hours
- User Replaceable Battery - Yes
- Input
- Adjustable Voltage Range - 97 – 144 VAC
- Circuit Breaker - 15 A
- Cord Length - 10 ft (3.0 m)
- Input Frequency Range - 57 Hz – 63 Hz
- Input Plug Type - NEMA 5-15P
- Input Voltage Range - 88 VAC – 144 VAC
- Nominal Input Voltage - 120 VAC
- Plug Style - Right Angle – 45° Offset
- Output
- Automatic Voltage Regulation - Single Boost
- On AC WaveForm - Sine Wave
- On Battery Frequency - 60 Hz ± 1%
- On Battery Voltage - 120 VAC ± 10%
- On Battery Waveform - Sine Wave
- Outlet Type - 6 – NEMA 5-15R
- Outlets – Battery & Surge Protected - 4
- Outlets – Surge-Only Protected - 2
- Outlets – Total - 6
- Output Power Factor - 0.57
- Overload Protection
- Internal Circuitry Limiting
- Circuit Breaker Protected
- Typical Transfer Time - 8 ms
- USB Charge Port - No
- VA - 700 VA
- Watts - 400 W
- Surge Protection & Filtering
- EMI/RFI Filtration - Yes
- Network Protection RJ45 - 1-in / 1-Out (10/100/1000)
- Surge Suppression (Joules) - 1150 J
- Management & Communications
- Audible Alarms
- Battery Mode
- Low Battery
- Overload
- Fault
- HID Compliant USB Port - Yes
- LCD - Multifunction LCD
- LED Indicators
- Power On
- Wiring Fault
- Management Cable - USB Cable
- SNMP / HTTP Remote Monitoring - Yes – with optional RMCARD205
- Serial Port - 1 Dry Contact
- Software (Free Download) - PowerPanel Business
- Audible Alarms
- Physical
- Color - Black
- Form Factor - Rackmount
- Material of Construction - Metal
- Rack Height - 1U
- Dimensions
- Physical Dimensions (WxHxD) - 17.05 x 1.73 x 9.04in (43.31 x 4.39 x 22.96cm) (433 x 44 x 230mm)
- Weight - 18.3lb (8.3kg)
- Environmental
- Operating Elevation - 0 – 10000 ft (0 – 3048 m)
- Operating Relative Humidity - 0 – 95 % (non-condensing)
- Operating Temperature - 32 – 104 °F (0 – 40 °C)
- Storage Elevation - 0 – 50000 ft (0 – 15239 m)
- Storage Relative Humidity - 0 – 95% (non-condensing)
- Storage Temperature - 5 – 113 °F (-15 – 45 °C)
- Certifications
- Environmental - RoHS Compliant
- Safety
- UL1778
- CSA C22.2 No. 107.3
- FCC Class B
- DOE
- Warranty
- CEG Amount - $300000
- Connected Equipment Guarantee - Lifetime
- Extended Warranty Option - WEXT5YR-U1B
- Product Warranty - 3 Year Limited Warranty
