Shure MXA320 Table Array Microphone w/DSP - Aluminum

About: Shure MXA320 Table Array Microphone w/DSP - Aluminum

The MXA320 is the next evolution of Shure’s table array microphone that provides high quality audio capture and flexible configuration for AV conferencing environments including boardrooms, huddle rooms and conferencing rooms. It features Steerable Coverage Technology with onboard IntelliMix DSP, streamlined deployment with Designer System Configuration Software and intuitive remote management via ShureCloud, all housed in a familiar, compact, low-profile design.

• Steerable Coverage Technology lobe accuracy allows users to configure up to four simultaneous polar patterns
• Onboard IntelliMix DSP includes echo-cancellation and noise reduction to eliminate annoying distractions
• Remote device management, real-time device monitoring of device status and performance, and firmware updates with ShureCloud
• With Designer System Configuration Software, coverage can easily be viewed alongside other Microflex Ecosystem products in the room
• Housed in a familiar compact low-profile design
• Stylish round form factor complements any interior design without drawing attention
• Available in white, black, or aluminum finishes
• PoE powered
• LED status bar with configurable colors and brightness

Specifications

• General
  • Polar Pattern: Cardioid, hypercardioid, supercardioid, toroid, omnidirectional, bidirectional
    • All channels independently adjustable
  • Connector Type: RJ45
  • Cable Requirements: Cat 5e or higher (shielded cable recommended)
  • Power Requirements: Power over Ethernet (PoE), Class 0
  • Power Consumption: 5 W maximum
  • Control Software: Shure Designer or web application
  • Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
  • Storage Temperature Range: −29°C (−20°F) to 74°C (165°F)
  • Dimension: 1.4 x 5.3 x 5.3 inch (3.6 x 13.4 x 13.4 mm)
  • Weight: 0.8 lbs (362 g)
• Audio
  • Frequency Response (-3 dB): 100 Hz to 20 kHz
  • AES67 or Dante Digital Output
    • Channel Count: 6 total channels: 4 direct outputs, 1 automix output, and 1 AEC reference input
    • Sampling Rate: 48 kHz
    • Bit Depth: 24
  • Sensitivity (at 1 kHz, −15 dB gain setting): −21 dBFS/Pa
  • Maximum SPL (1 kHz at 1% THD, −15 dB gain setting): 115.2 dB SPL
  • Signal-To-Noise Ratio (Ref. 94 dB SPL at 1 kHz, −15 dB gain setting)
    • Cardioid: 75 dB
    • Toroid: 67 dB
  • Latency (Not including Dante latency): < 1.7 ms
  • Self Noise (−15 dB gain setting)
    • Cardioid: 19.2 dB SPL-A
    • Toroid: 26.8 dB SPL-A
  • Dynamic Range (−15 dB gain setting)
    • Cardioid: 96 dB
    • Toroid: 90 dB
  • Built-in Digital Signal Processing: Equalizer (4-band parametric), acoustic echo cancellation (AEC), automatic gain control (AGC), noise reduction, compressor, delay, mute, gain
  • Acoustic Echo Cancellation Tail Length: Up to 250 ms

What's in the Box

• 1x Aluminum Table Array Microphone
• 1x Cable-exit plug
• 1x Mounting tube wing nut
• 1x Rubber Isolation Ring
• 4x Nylon cable ties
