Tascam DR-07XP 2-Channel 32-Bit Float Handheld Recorder w/USB-C, Adjustable Mics

About: Tascam DR-07XP 2-Channel 32-Bit Float Handheld Recorder w/USB-C, Adjustable Mics

The TASCAM DR-07XP portable handheld recorder makes it easy to capture pro-quality recordings for music, audio-for-video, meetings, dictation, and more. With 32-bit float recording mode, you'll never need to worry about setting audio levels, and adjustable stereo condenser microphones give you full control over your sound. With easy one-handed operation, the DR-07XP makes it simple to start recording with minimal setup time.

• 2-channel portable handheld audio recorder with microSDXC card storage
• 32-bit float recording mode ensures low-noise, distortion-free recordings
• Stereo AB/XY condenser microphones handle loud environments and sources (up to 125dB SPL)
• 2-in/2-out USB-C audio interface for recording directly to your computer
• Up to 17.5 hours operation with 2 x AA alkaline batteries
• Recording modes include 32-bit float/24-bit/16-bit, 96kHz/48kHz/44.1kHz
• microSDXC (up to 512GB) cards can be used as recording media
• USB Type-C port
• Stereo mini jack for external stereo microphones (provides plug-in power) / External line input
• Support multiple menu languages (ENG/FRA/DEU/ITA/ESP/RUS/PRT/JPN/CHI/KOR)
• Long recordings as MP3 files possible
• Various recording function (Auto rec, Self timer, Pre rec)
• Overdubbing function
• Limiter and Peak reduction
• Three low-cut filter levels (40/80/120Hz)
• Auto Tone output for use with DSLR camera
• Reverb effect for vocal and instrument resonance
• Mark function
• 128×64 pixel graphic LCD with backlight
• Tripod mounting point attaches to any standard tripod
• Stereo mini line output and headphone output
• Speed change (VSA) function for adjusting the speed from 0.5 to 2.0 times (in 0.1 increments)
• Playlist function
• Built-in monaural speaker makes it easy to check your recordings
• Chromatic tuner for tuning musical instruments before recording

Capture Pro-Level Recordings Every Time

With its 32-bit float recording mode, the DR-07XP ensures your audio recordings will always be clear, distinct, and free of distortion that could ruin your recording — and you’ll never need to worry about setting input levels.

Adjustable Stereo Condenser Microphones

The DR-07XP features unidirectional stereo condenser microphones with adjustable A/B or X/Y configurations, allowing you to capture incredibly vivid stereo recordings in any setting.

Simplicity in Your Palm

With the DR-07XP, the complexities of audio recording are a thing of the past. Easily access every feature from the palm of your hand. Plus, the backlit LCD screen means no squinting; just clear and concise navigation any time of day, in any environment.

Your Portable Recording Studio

The DR-07XP isn't only a powerful portable recorder — it's also a 2-in/2-out USB-C audio interface you can use to record anywhere, directly to audio recording software on your Mac or PC.

Ideal for Musicians

The DR-07XP is a fantastic portable recording solution for musicians with its high-quality microphones, 32-bit float recording, built-in tuner, reverb, overdubbing and more.

On Location

With its compact size, the DR-07XP can travel anywhere for exceptional field recording. Choose from three different low cut filter options for getting rid of unwanted noises. As a companion for video, the DR-07XP can attach easily to tripods and the Auto Tone output for cameras makes post-production a simple task.

Record Anything, Anywhere

From dialogue to vlogs, whether you're in an alley or a recording booth, the DR-07XP captures clear, crisp audio with ease. In addition to the built-in mics, use the stereo mini jack to add microphones with plug-in power or external line inputs to capture audio from any source in mono or stereo. Connect the unit to a computer via USB-C for use as a USB microphone.

Specifications

• Recorder
  • Recording media/file systems: microSD cards, microSDHC cards, microSDXC cards (up to 512 GB)
  • Recording/playback formats
    • WAV (BWF)
      • Sampling frequency: 44.1 kHz / 48 kHz / 96 kHz
      • Quantization bit depth: 16-bit / 24-bit / 32-bit float
    • MP3
      • Sampling frequency: 44.1 / 48 kHz
      • Quantization bit depth: 32 / 64 / 96 / 128 / 192 / 256 / 320 kbps
  • Maximum number of input channels: 2
  • Maximum number of recordable tracks: 2
• Analog audio input/output ratings
  • MIC/EXT IN jack (can provide plug-in power)
    • Connector: 3.5mm (1/8") stereo mini jack
    • Input Impedance
      • 18 kΩ or more (when plug-in power is turned off)
      • 2 kΩ or more (when plug-in power is turned on)
    • Nominal input level: -20 dBV
    • Maximum input level: -4 dBV
  • PHONES/LINE OUT jack
    • Connector: 3.5mm (1/8") stereo mini jack
    • Output impedance: 12 Ω
    • Nominal output level: -14 dBV (10kΩ loaded)
    • Maximum output level: +2 dBV (10kΩ loaded)
    • Maximum output: 20 mW + 20 mW (32 Ω load)
    • Working impedance: 16 - 250Ω
  • Built-in Speaker
    • Output 0.3W (monaural)
• USB
  • Connector: USB Type-C
  • Format
    • USB 2.0 High Speed Mass Storage Class
    • USB 1.1 Full Speed Audio Class
• USB Audio
  • Sampling rate: 44.1 / 48 kHz
  • Quantization bit depth: 24-bit
  • Number of inputs: 2 channels (output from this unit)
  • Number of outputs: 2 channels (input to this unit)
• General
  • Power
    • 2x AA batteries (alkaline or NiMH)
    • USB bus power (5V/0.5A) from a computer, etc.
    • TASCAM PS-P520U AC adapter (sold separately)
  • Power consumption: 1.7 W (maximum)
  • Operating temperature range: 0 – 40 °C / 32 – 104 °F
  • Dimensions (WxHxD)
    • Mic closed: 2.68 x 6.28 x 1.06 inch (68 x 159.6 x 27.0mm)
    • Mic open: 3.56 x 6.28 x 1.06 inch inch (90.3 x 159.6 x 27.0mm)
  • Weight
    • With batteries: 184 g / 0.406 lb
    • Without batteries: 136 g / 0.30 lb

What's in the Box

• 1x DR-07XP
• 1x Safety guide (including warranty)
• 1x TASCAM ID registration guide
