Pathway Connectivity DMX Repeater, Rear Panel 5-Pin XLR Female (DMX Only)

About: Pathway Connectivity DMX Repeater, Rear Panel 5-Pin XLR Female (DMX Only)

The Pathway DMX Repeater series of opto-splitters are an essential component of DMX distribution systems, permitting star-wiring configurations while isolating and protecting equipment from electrical faults.

Other advanced features include input sensing, prioritization between two controllers, or HTP merging of two sources with one source able to roam - ideal for incorporating remote focus units.

Features

• 8 DMX512 Outputs
• 1 DMX512 Input, 1 Passive DMX512 Thru
• DMX line termination switch
• Gold-plated XLR Contacts
• No fuses - self-resetting port protection recovers from voltage faults
• Truss-mount (PWACC TMLG) and Wall- mount (PWACC WMLG) accessory kits available
• Silent, fan-less operation
• Rack-mount ears included
• Also available in DIN-mount (PWREP DIN) and Wall-mount (PWREP WM) form factors

Specifications

• General
  • Control Device Type -  Interface Device
  • Mounting Location -  Portable
  • Product Type -  Opto Splitter
  • Network Compatibility -  DMX
  • Networkable Control -  Yes
  • Voltage Rating 100-240
  • # of Comm. Ports 8
  • Receiving Protocol DMX
  • Sending Protocol DMX
  • Dimming Protocol DMX
  • Compliance Listing -  BAA, ROHS
  • Regulatory Compliance -  CE, ETL
  • Series -  PWREP
  • Compliance -  ANSI E1.11 DMX512-A R2013
• Electrical
  • Input Ratings
    • 100-240VAC, 50/60Hz wide-range power input
    • 0.08A max power consumption
  • Isolation & Fault Protection
    • 3000V isolation between DMX data links
    • 250V fault protection on DMX ports
  • Regulatory Compliance -  UL, CE
• Environmental
  • Operating Temperature -  14°F to 122°F (-10°C to 50°C)
  • Relative Humidity -  5-95%, non-condensing
  • Standard Compliance -  RoHS 2011/65/EU + A1 2015/863
• Mechanical
  • ​Dimensions (WxHxD) -  17.0 x 1.7 x 7.0in (433 x 43 x 178mm)
  • Weight -  5.2 lbs (2.4 kg)
