Astera AX2 PixelBar Wireless LED Bar 100CM

Model: AX2-100

Astera AX2 PixelBar Wireless LED Bar 100CM
  • Free Shipping!
  • Not In-Stock - Available to Order
  • Not yet reviewed

More models to choose from:


About: Astera AX2 PixelBar Wireless LED Bar 100CM

Astera’s Wireless PixelBar is a linear wash fixture with built-in battery pack. Each of its LEDs can be individually addressed and offers ultra-high color rendering, digital color calibration and a native 21° beam. Thanks to its smart stands, hanging bracket, connectable endcaps and the integrated airline track it can be quickly assembled in numerous ways and is suitable for a wide variety of applications such as concert/touring, corporate events, TV etc.

The PixelBar will be available in 1m (16 x 10W LEDs) and 50cm (8 x 10W LEDs).

Features unique to AX2 PixelBar

  • Talkback+ - Detect all available lights, set them up, check their status, configure DMX addresses and DMX profiles.
  • Seamless Runtime - Set the length of your production and be sure that your lights won`t run out while still getting the maximum brightness.
  • TruColor Calibration - Individually calibrated lights lead to 100% color consistency and exact color reproduction of color temperature and filter gels.
  • Effects - Quickly build programs out of colors and effects, trigger them or make them match a beat.
  • Flicker Free - Scrambled PWM technology to avoid flickering when filming.
  • Green/Magenta Correction - Adjust green/magenta during content creation to reduce postproduction work.
  • Scheduled StandBy - Switch lights into power-saving standby and schedule them to wake up when the production starts.
  • Dynamic PowerBoost - This exclusive feature makes the light able to display the maximum brightness at all time and intensify non-white colors.
  • Emergency Lights - Switches to white light when AC power is cut to keep your event save
  • Anti-Theft - The lights give visual and audible alarm and send notification to the AsteraApp if they are being moved during an event.
  • DJ Feature - Auto BPM analyzes the beat and matches programs to it, flash buttons can trigger special effects while being held down.
  • Other Features - The AsteraApp is packed with many additional items and new features are frequently added via software update.



  • Colors: Red, Green, Blue, Mint, Amber
  • Total LED power: 160W / 80W
  • Power draw: 80W / 40W
  • TLCI (3200k-6500k)*: ≥96
  • CRI (3200k-6500k)*: ≥96
  • Light output – 2700k, 3200k,5500k (100)*:  3600lm, 4460lm, 4530lm
  • Light output – 2700k, 3200k,5500k (50)*: 1800lm, 2230lm, 2265lm
  • Strobe: 0-25Hz
  • Pixels: 16 (8)

(*Typical value)


  • Battery Lifetime: 70% after 300 cycles
  • Battery Runtime: Up to 20 hours
  • Charging time (nominal): 5 Hours
  • Input Voltage : 110 – 240V, 50/60 Hz


  • Backside Display with HSI control
  • Infrared
  • Wireless Frequencies: CRMX 2.4GHz, UHF
  • Range: 300m | 330 Yards
  • CRMX Receiver: Built-in


  • Housing: Aluminum
  • IP Rating: IP65
  • Ambient Temperature: 0-40˚C | 32-104˚F
  • Weight (50): 4.5 kg (9.9 lbs)
  • Weight (100): 7.4 kg (16.3 lbs)
  • Dimensions with hook 50 (mm/inches): 520 x 165 x 65 / 20.5 x 6.5 x2.6
  • Dimensions with hook 100 (mm/inches):1020 x 165 x 65 / 40.1 x 6,5 x 2,6
  • Dimensions without hook 50 (mm/inches): 500 x 165 x 65 / 19.7 x 6.5 x2.6
  • Dimensions without hook 100(mm/inches):1000 x 165 x 65 / 39.4 x 6.5 x 2.6

Videos: Astera AX2 PixelBar Wireless LED Bar 100CM

Reviews: Astera AX2 PixelBar Wireless LED Bar 100CM

There are currently no product reviews.

Warranty: Astera AX2 PixelBar Wireless LED Bar 100CM Warranty:

30 Days

Manufacturer's Warranty:

  • 2 Years warranty on electronics
  • 3 Month warranty on batteries
