BLUSTREAM AD11AU Analogue Audio Delay Processor w/ Volume Control
Model: AD11AU
About: BLUSTREAM AD11AU Analogue Audio Delay Processor w/ Volume Control
Our AD11AU has been designed to help correct audio delays incurred when separating audio and video signals in an AV system. The AD11AU can add a delay of up to 1 second selectable in 15 increments and has a volume adjustment of -75dB to 0dB.
Features
- In-line 2ch analog audio delay with line-level volume control
- Supports 48KHz / 24 bit sample rates
- Selectable audio delay from 50-1,000ms
- 0-500ms in steps of 50ms
- 500-1,000ms in step is of 100ms
- Adjustable line level volume control from -75dB to 0dB
Specifications
- Audio Input Connectors: 2 x RCA analog left/right
- Audio Output Connectors: 2 x RCA analog left/right
- Audio Delay: Rotation switch
- Volume Control: Rotation switch
- Operating Temperature: 32°F to 104°F (-5°C to +55°C)
- Storage Temperature: -4°F to 140°F (-25°C to +70°C)
- Power Supply: 5V/1A DC
- Casing Dimensions (WxDxH): 2.76 x 0.98 x 2.87 inch (70 x 25 x 73mm)
- Shipping Weight: 0.88 lb (0.4kg)
What's in the Box
- 1x AD11AU
- 1x 5V/1A DC Power Supply
- 1x Mounting Kit
- 1x Quick Reference Guide
UPC: 9340242003195
