Blackmagic Design Media Dock Ultra

About: Blackmagic Design Media Dock Ultra

Blackmagic Media Dock Ultra accelerates your post production workflow by enabling incredibly high speed network sharing and upload from up to 3 Blackmagic Media Modules from Blackmagic URSA Cine cameras. 2 x 100G Ethernet ports allow multiple edit stations to connect and edit directly. Blackmagic Media Dock Ultra also has dual AC power inputs for redundancy and 2 x SDI and an HDMI output for live monitoring of media in real time on a TV or monitor.

Specifications

• Connections
  • 100G Ethernet: 2 x 100G QSFP28 connections.
    • Each 100G port can be assigned an independent IP address and subnet mask for up to 200G bandwidth and load balancing when used with a managed switch.
  • 1G Management: 1 x RJ45 Ethernet. Supports 10/100/1000 BASE-T. For Cloud Store Setup utility and software updates.
  • SDI Monitor Outputs: 2
  • HDMI Monitor Outputs: 1
  • SDI Rates: 1.5G, 3G.
  • Computer Interface: 1 x USB-C for Cloud Store Setup utility and software updates.
  • Power: 2 x IEC C14 power inputs.
• File Sharing Protocol
  • Protocol
    • NFS (HFS+ formatted disks only)
    • SMB
  • Computer Connections: 200 max.
• Cloud Synchronization
  • Blackmagic Cloud
  • Amazon Web Services S3 sync
• Storage
  • Storage Type: Up to 3 Blackmagic Media Modules.
  • External Storage Format: Blackmagic (formatted in camera)
• Displays
  • Status Indicator: LED bezel indicator lights around media module bays.
  • Monitor Out Displays: Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graph.
  • SDI Monitor Out Standards: 1080p50, 1080p59.94, 1080p60
  • HDMI Monitor Out Standards: 1080p50, 1080p59.94, 1080p60
• Device Control
  • External Control: USB-C or Ethernet for configuration and software updates.
• Software
  • Software Included
    • Blackmagic Cloud Setup Utility
    • Blackmagic Proxy Generator Lite
    • Internal software upgrade via Blackmagic Cloud Setup using USB-C port
• Operating Systems
  • Mac
    • Mac 15.0 Sequoia
    • Mac 26.0 Tahoe or later
  • Windows
    • Windows 10, 64-bit
    • Windows 11
• Power Requirements
  • Power Supply: 2 x 100 ‑ 240V AC 50/60Hz internal power supplies.
  • Power Inputs: 2 x IEC C14 sockets.
  • Power Usage: x
• Environmental
  • Operating Temperature: ​0° to 40° C (32°to 104° F)
  • Storage Temperature: -20° to 60° C (-4° to 140° F)
  • Relative Humidity: 0% to 90% non‑condensing
• Physical Installation: 3 rack units.

What's Included

• Blackmagic Media Dock Ultra
• Welcome wallet with QR code for software download

NOTE: Media Dock only. Media Modules displayed are not included.
