BrightSign XT1145 8K Digital Signage Player - Expanded I/O

About: BrightSign XT1145 8K Digital Signage Player - Expanded I/O

BrightSign XT5 Series future proofs deployments with confidence by delivering power, performance, and flexibility to create captivating experiences. This product line consists of three ultra-thin models, all capable of playing the highest quality video up to 8K resolution and running sophisticated HTML motion graphics with remarkable performance. XT5 offers the most extensive set of HDMI and connectivity ports. Its HDMI input option plays live TV or video from outside sources. Dual HDMI outputs* can power two screens simultaneously for video walls or dual-screen signage applications. Streamline installations with Power over Ethernet (PoE+) and utilize a comprehensive set of I/Os for add-on devices and engagement. BrightSign XT5’s versatility and power guarantees exceptional signage experiences for years to come.

• *Dual HDMI outputs is only available with the Multiplex model

Future-Proof Performance

Power and versatility to create captivating experiences for years to come.

• Plays brilliant 1080p to 8K video
• Supports dual 4K video decoding to drive two screens at once*​
  • Dual 4K decoding is only available with the Multiplex model
• Runs highly responsive motion graphics at high frame rates
• Streamlined deployments with PoE+ and comprehensive I/O capabilities
• Efficient, ultra-thin design with anodized aluminum enclosure
• Runs BrightSignOS

Next-Gen Motion Graphics

Cutting-edge graphics capabilities.

• Powers sophisticated WebGL, HTML, CSS and JavaScript graphics
• Runs highly responsive motion graphics at high frame rates
• Supports responsive multi-touch, pinch, and zoom interactions
• Optimized for ultra-smooth 3D motion graphics and data visualizations

High Quality Video

Drives stunning HD experiences from 1080p to 8K.

• Runs brilliant full resolution graphics and video from 1080p to 8K video
• Supports a broad range of unique and customizable resolutions at various frame rates
• Delivers industry-best 60p, 10-bit decoding
• Optimized storage with cutting-edge video codecs

Connect & Create

Creates immersive and powerful experiences at scale.

• Offers BrightSign’s most expansive set of connectivity options yet
• Engage your audience dual USB, serial, GPIO, IR, and digital/analog audio
• Streamlined deployments with Gigabit speed PoE+
• Control live TV with an HDMI In port

Dual Screen Deployments

Deploys brilliant Full HD and 4K dual-screen experiences.

• Offers dual HDMI outputs to drive two screens at once*
  • Dual HDMI outputs are only available with the Multiplex I/O model
• Supports dual 4K* or dual Full HD video decoding
  • Dual 4K decoding is only available with the Multiplex I/O model
• Streamline video wall and 2-screen deployments with a single players
• Play a single video or HTML canvas of content across 2 displays for video wall applications
• Assign independent content to play from each HDMI output for multi-screen applications
• Use the HDMI Input to play live TV spread across two screens

Powered by Purple

BrightSignOS is the only purpose-built operating system for digital signage - and it's found exclusively in BrightSign players. Here’s what it means to be Powered by Purple.

• Secure: BrightSignOS delivers unmatched security, keeping your players, connected devices, and network safe from any potential risks.
• Reliable: With unrivaled uptime across millions of players, BrightSignOS's self-healing capabilities and real-time monitoring ensure uninterrupted operation and peace of mind.
• Superior: BrightSignOS is able to run any type of content, resolution, connected device, and technology integration, making it easy to create dynamic and sophisticated digital experiences.
• Sustainable: Easy to maintain, power-efficient, and updateable, BrightSignOS is the long-lasting and sustainable choice for digital signage.

Specifications

• Model -  XT1145 Expanded I/O
• VIDEO & HTML5 ENGINES
  • HTML5 performance level -  Executive: Runs powerful 3D WebGL motion graphics
  • Video Decoding
    • Single 8K60p 10-bit
    • Single 4K60p 10-bit
    • Full HD
    • Dual Full HD
  • 4K video rotation -  Yes
  • Full HD video rotation -  Yes
  • Full HD images & graphics -  Yes
• MEDIA FORMATS
  • Video Codecs
    • 8K H.265 at 60p
    • 4K H.265 and H.264 at 60p
    • Full HD H.265, H.264 (MPEG-4, Part 10), and MPEG-2
  • Video Containers
    • 8K .ts, .mov, .mp4, .mkv
    • 4K .ts, .mov, .mp4, .mkv
    • Full HD .ts, .mpg, .vob, .mov, .mp4, .m2ts
  • Video Resolutions
    • 8K - 7680x43 20x23.97/24/25/29.97/30/50/ 59.94/60p
    • 4K - 4096x21 60x23.97/24/25/29.97/30/50/ 59.94/60p 3840x2160x23.97/24/25/29.97/ 30/50/59.94/60p
    • Full HD- 1920x1080x23.97/24/25/29.97/ 30/50/59.94/60p
  • Supports additional & customizable resolutions: includes unique, non-standard aspect ratios at various frame rates -  Yes
  • Images: BMP, JPEG, PNG -  Yes
  • Audio: MP2, MP3, AAC and WAV (AC3 is passed through) -  Yes
  • HTML5:.html, Chromium- based, CSS, JavaScript, WebGL -  Yes
• HARDWARE INTERFACES
  • HDMI Outputs -  1
  • HDMI 1 Output: -  HDMI 2.1a
  • HDMI 2 Output: -  X
  • HDMI In: -  HDMI 2.0a
  • Ethernet -  Gigabit with PoE+
  • USB-A: provides 5V/1A power to peripheral devices -  Yes
  • USB-C: supports high-speed host mode & provides 5V/1A power to peripheral devices -  Yes
  • GPIO: 12-pin Phoenix Connector with 8 bi-directional Ports -  Yes
  • IR: 3.5mm In/Out -  Yes
  • Serial: 3.5mm RS-232 -  Yes
  • Audio: 3.5mm Output (Analog or SPDIF) -  Yes
  • Primary storage: External microSD card slot -  Yes
  • Optional storage: M.2 PCIe Interface for NVME SSD Storage -  Yes
  • Optional Wi-Fi/Bluetooth: E Key M.2 Interface for WD-105 module -  Yes
  • Status LEDs -  Yes
  • Reset & Service Buttons -  Yes
  • Real Time Clock with 14-day life -  Yes
  • Locking Power Connector -  Yes
• ACCESSORIES
  • BP200 & BP900 USB Button Pads -  Yes
  • MicroSD Class 10 Cards (various capacities) -  Yes
  • WD-105 Dual Antenna Wireless/Bluetooth Module -  Yes
  • BrightSign Mobile USB Modem -  Yes
  • CBL-USBC to USBA and 3.5mm Serial -  Yes
  • GP800-C: USB C to GPIO 12-pin Cable Kit -  Yes
• SOFTWARE & SERVICES
  • BrightSign OS -  Yes
  • Free BrightAuthor:connected or BrightAuthor software -  Yes
  • Free Control Cloud -  Yes
  • Subscription-based BSN.cloud -  Optional
  • BrightSign Mobile Service -  X
• MISCELLANEOUS
  • Anodized aluminum enclosure for extended operating temperatures -  Yes
  • Dimensions (WxDxH) -  9.39 x 7.32 x 0.76 Inch / 238.62 x 185.9 x 19.19 mm
  • Player weight -  1.39 lbs. / 0.63 kg
  • Power -  12V / 3A
  • Multi-Country Power & Regulatory Approvals -  Yes
  • Built-in Wall Mounting Brackets -  Yes
  • Warranty -  1 year, parts and labor
