AIDA UHD-X3L 4K HDMI POV Camera

Model: UHD-X3L

AIDA UHD-X3L 4K HDMI POV Camera
AIDA UHD-X3L 4K HDMI POV Camera
AIDA UHD-X3L 4K HDMI POV Camera
  • Free Shipping!
  • Not in-Stock: Estimated Lead Time 7-10 Days
  • Not yet reviewed




About: AIDA UHD-X3L 4K HDMI POV Camera

The UHD-X3L is a professional micro POV camera with 3X optical zoom capabilities. Ideal for wide angle viewing, the UHD-X3L is robust in its features, integrating 4K UHD Progressive CMOS sensors with a digital image processor to maintain sharpness in quality without compromise. The UHD-X3L is great under low light conditions with its motion compensated temporal noise reduction filter. Designed for versatility, durability, and cost effectiveness for smooth integration into any broadcast, professional, or corporate AV environment.

MAIN FEATURES

  • 4K UHD 1/2.5 Progressive Scan CMOS sensor captures sharp and vivid UHD video even under very low light conditions.
  • 3X optical zoom features 25~78 wide angle of view.
  • Built-in zoom lens offers zoom, focus and iris control.
  • Advanced digital imaging processor provides vivid and detailed images by utilizing Dynamic Range, Auto White Balance, and Noise Reduction.
  • Superb motion-compensated temporal noise reduction filter for motion video without blurring.
  • OSD control breakout cable with power input and RS-485 for remote communication.
  • Perfectly suited for huddle rooms, broadcast, pro audio/video, and security.
  • Versatile, compact, and rugged design.

SPECIFICATIONS

Video

  • Image Sensor 1/2.5" Progressive CMOS
  • Sensor Size Diagonal 7.20mm
  • Effective Pixels Horizontal: 3840, Vertical: 2202
  • Pixel Size 1.62 μm (H) x 1.62 μm (V)
  • Resolution
    • 2160p: 3840 x 2160
    • 1080p / 1080i : 1920 x 1080
    • 720p : 1280 x 720
  • Resolution/Rate
    • 4K2160p : 30 / 29.97 / 25 / 24
    • 1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24
    • 1080i : 60 / 59.94 / 50
    • 720p : 60 / 59.94 / 50
  • Output HDMI 1.4
  • Color Space 4:2:2 (YCbCr) 10 bit

Function

  • White Balance AWB / AE / AF
  • Exposure Full Auto, Bright, Shutter Priority, Iris Priority, Manual
  • Other WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction,
  • Digital Slow Shutter, Black Level Compensation, Flicker Detection

Lens

  • Lens 3X Optical Zoom Lens, 3.85mm/78° (Wide) ~ 13.4mm/25° (Tele)

Standard

  • SMPTE SMPTE 292M, SMPTE 424M, SMPTE 2081-10

Physical

  • Camera Control RS-485, OSD Button
  • Operation Temp 32°F - 104°F
  • Dimension 48mm x 48mm x 83.09mm / 1.89" x 1.89" x 3.27"
  • Weight 140g / 0.30lbs
  • Power 12 VDC (+9 - +15VDC)

UPC: 720260897584

Reviews: AIDA UHD-X3L 4K HDMI POV Camera

There are currently no product reviews.


Warranty: AIDA UHD-X3L 4K HDMI POV Camera

AVShop.ca Warranty:

30 Days

Manufacturer's Warranty:

AIDA warrants to the original owner-user that this AIDA product will be free from defects in workmanship or material. This warranty is limited to one(1) year from the original purchase date, whether or not actual use begins on that date.
