Turtle AV Dante Bluetooth Wall Plate - Black

About: Turtle AV Dante Bluetooth Wall Plate - Black

The Turtle AV Dante Bluetooth Wallplate is a professional Bluetooth audio interface designed for installed Dante audio systems. It allows users to stream two-channel audio from a Bluetooth-enabled device directly into a Dante network, making it ideal for meeting rooms, classrooms, hospitality spaces, houses of worship, retail environments, and other commercial audio installations.

• Dante network wall plate interface for Bluetooth inputs
• Bluetooth V5.1, SBC/AAC/APTX/APTX-LL/APTX-HD, up to 192 kHz @ 24-bit
• Configurable Bluetooth device naming for simple device discovery
• Supports Bluetooth input switching
• Supports simultaneous connection of up to 2 Bluetooth devices
• Supports Bluetooth volume adjustment, with a volume range from 0 to 100
• Supports Bluetooth previous track, next track, and pause functions
• Supports display of album information from the audio source
• Supports Bluetooth software upgrades via the USB-C port
• Dante 44.1, 48, 88.2, and 96 kHz sample rates @ 16, 24, or 32-bit
• Configurable Dante device latency, supporting 2, 3, 4, 5, or 10 ms via Dante Controller
• Supports AES67 RTP audio transport
• Features Class 0 IEEE 802.3af PoE for powering the product from any PoE switch
• Can also be powered via a local 12 V DC adapter, not included, when the network switch does not support PoE
• Front panel button, TCP/IP, and Web GUI control

The Dante Bluetooth Wallplate can be powered via PoE or 12 V DC and is configured through its built-in WebUI. From the WebUI, users can manage audio settings, network configuration, presets, firmware updates, and system utilities. For advanced integration, the device also provides IP-based API control, allowing third-party control systems to manage pairing, connection status, playback, volume, and metadata display.

Bluetooth. Dante. Installed.

Fits the infrastructure you already have. Available in US 1-Gang Decora, this professional hardware is designed to disappear into the wall and integrate seamlessly with your Dante network.

Bluetooth. Dante. Controlled.

Built API-first. A fully managed Dante endpoint on your network. The open API gives your control system total command over the device, from handshake to stream with control over playback, volume, pairing, and clearing connected devices.

Bluetooth. Dante. Connect.

Manage the handshake programmatically. Trigger discovery mode, authorize new devices, or drop a connection the moment the user leaves the room. You decide who connects, and when.

Bluetooth. Dante. Live.

Spotify, Apple Music, Tidal, YouTube Music. It doesn’t matter. Map transport controls like Play, Pause, and Skip directly to your touch panels or keypads. Drive the audio without ever asking the user to unlock their phone.

Bluetooth. Dante. Displayed.

Context is key. Use real-time metadata to pull artist names, song titles, and album info. If it’s playing on the device, it can be mapped to your interface.

Bluetooth. Dante. In Black & White.

Available in Black and White. Two finishes that match the architecture. Simple.

Audio stuff.

This Wall Plate delivers high-quality two-channel Bluetooth audio to Dante 2CH digital audio, supporting Bluetooth V5.0 with advanced codecs like SBC, AAC, APTX, APTX-LL, and APTX-HD, offering audio up to 24-bit/192kHz. The Dante audio output is sampled up to 24-bit/96kHz, ensuring clear, professional-grade sound. With configurable Dante audio delay options of 2, 3, 5 or 10 milliseconds providing precise timing and low-latency performance.

DSP control via WebGUI

The built-in DSP WebGUI makes managing your Dante Wall Plate super easy and delivers even more value to this little powerhouse. With the WebGUI, every feature is at your command.

• Configure Audio Precisely - Adjust output settings, manage EQ profiles, and control audio delay for Analogue and Dante outputs.
• Save and Recall Presets - Create up to 5 customizable presets for quick scene changes, perfect for dynamic setups.
• Monitor and Manage Network Settings - Switch between DHCP and Static IP modes, configure Telnet ports, and use the domain name for quick access.
• Advanced System Utilities - Modify passwords, reboot the system, update firmware, and export/import settings with ease.
• Streamlined Setup - Control everything from input sources to auto-standby times, all through an easy-to-use interface.

Easy Control. 100% Dante Software compatible.

Turtle AV Dante Wallplates are fully compatible with Dante Controller, Dante Domain Manager, and Dante software applications, the Dante Bluetooth Wallplate provides a simple, secure, and controllable way to add Bluetooth audio sources to professional Dante systems.

TAA Compliant.

Turtle AV products sold in the USA are TAA compliant, meeting U.S. government standards for procurement. This ensures they can be confidently used in federal contracts, adhering to strict ethical sourcing and manufacturing regulations.

5 Year Warranty with Advance Replacement.

Turtle proudly offers a 5 Year warranty on Dante Wallplate fam products. Warranty is 5 years from date of purchase and we are also proud to offer a no hassle advance replacement warranty on all our products.

Specifications

• Technical
  • Input: Two-channel Bluetooth audio
  • Output: Dante digital audio
  • Control Method: WebUI, API
  • Network Bandwidth: 100Mbps
  • Audio Latency: Configurable Dante device latency
  • (Supports 2, 3, 4, 5 or 10ms configurable using Dante Controller)
  • Audio Formats
  • Bluetooth IN: Digital audio input, V5.1, SBC/AAC/APTX/ APTX-LL/APTX-HD, 2CH, 44.1K-48kHz 16/24Bit
  • Dante IN/OUT: Digital audio 4CH, 44.1K-96kHz 16/24Bit
  • Frequency Response: 20Hz to 20kHz
  • Audio S/N Ratio: ≥ 100dB
  • Audio THD+N: ≤ 0.1%
  • Transmission Distance: 328ft/100m (CAT6/6A/7)
  • ESD Protection: IEC 61000-4-2
  • ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
• Connections
  • Input: 1x Bluetooth input [Digital audio, internal antenna] [Bluetooth in V5.1, SBC/AAC/APTX /APTX-LL/ APTX-HD, 44.1K-48kHz 16/24Bit]
  • Output: 1x DANTE(PoE) [RJ45 connector, supporting PoE] [Digital audio out, 44.1K-96kHz 16/24Bit]
  • Others
    • 1x SERVICE [USB-C port, 12-pin female] 1x PAIR button with blue LED
    • 1x DC 12V [2pin-3.5mm phoenix connector]
• Mechanical
  • Power Supply: DC input: 12V/1A
  • Power Consumption: PoE input: PoE IEEE802.3af Class 0
  • Operating Temperature: 1.8W (Max)
  • Storage Temperature: 32°F ~ 104°F / 0°C ~ 40°C
  • Operating Humidity: -4°F ~ 140°F / -20°C ~ 60°C
  • Storage Humidity
    • 20% ~ 80% (Relative humidity, non-condensing)
    • 10% ~ 90% (Relative humidity, non-condensing)
  • Housing: Plastic panel + Iron chassis
  • Color: Black panel + Silver chassis
  • Dimensions (WxDxH): 1.77 x 1.58 x 4.13 inch (45 x 40 x 105 mm)
  • Weight: 0.33 lbs (149g)

What's in the Box

• 1x Bluetooth Audio to Dante 2x2 Wall Plate
• 1x 2pin-3.5mm Phoenix Connector (male)
• 1x Decorative Panel
• 2x American Standard Slotted Semi-countersunk Head Screw (6#-32)
• 2x Self-tapping Screw (-4*12)
• 2x Rubber Gasket
• 1x User Manual
