Deity THEOS DBTX D-UHF Bodypack Transmitter (Global Version)

About: Deity THEOS DBTX D-UHF Bodypack Transmitter (Global Version)

International Model. No Shipping to USA

As a filmmaker, sound is one of the most important aspects of your work. There is nothing more frustrating than discovering that your audio is unusable due to interference, dropped signals or other issues. This is where the Deity Theos Digital Wireless Microphone System comes in. This state-of-the-art system is designed to make your audio recording process seamless and stress-free.

• Uses a Wideband UHF spectrum rather than the crowded 2.4Ghz spectrum. Frequencies span between 550-960 MHz (the actual band size and spectrum will depend on which block / regional kit that is purchased)
• Transmitter features a built-in recorder for backup files. The onboard recorder features both 24-bit and 32-bit float formats so you never have to worry about gain staging on your backup WAV files. Perfect for avoiding dropped signals and wireless interference.
• Recordings are saved to a Micro SD card, up to 128Gb in size
• The transmitter can wirelessly sync its timecode to that of the Deity TC-1 timecode generator. Timecode ensures your backup WAV files will sync with your master file in post.
• The transmitter can be remotely controlled via the Sidus Audio app. Remote control features include frequency scanning and frequency assignment, frequency coordination between multiple receivers, gain staging, and remotely triggering the backup recorder
• Full Color LCD screen showcasing the status of the device
• CNC milled aluminum chassis
• SMA antenna ports so you can swap them out to fine tune your antenna to your frequency block or replace them if they get damaged. Also makes transporting gear more compact in its case

Specifications

• RF Modulation -  Proprietary Digital RF Modulation
• RF Freq Ranges
  • 550~608MHz (up to 100mW)
  • 614~616MHz (up to 20mW)
  • 653~663MHz (up to 20mW)
• RF Frequency Step -  100KHz
• RF Bandwidth -  200KHz
• RF Power -  0 / 20 / 25/ 50 / 100 mW – Software Selectable
• Minimum Frequency Spacing -  700KHz
• Antenna Connector -  50 Ω SMA
• Dynamic Range -  123dB
• Distortion -  <0.5%
• Frequency Response -  20~20KHz
• Low Cut -  0FF/75Hz/100Hz/150Hz
• Mic Power -  MIC-3V、MIC-5V、LINE
• Mic Connector -  3.5mm TRS Standard
• Input Gain -  0~+30dBu
• ADC Bit-Depth -  2x 24-Bit
• ADC Sampling-Rate -  48KHz
• Battery Life -  Up to 12+ Hours w/ 2x Lithium AA
• Dimensions (HxWxD) -  88.45 x 65 x 17.8mm
• Weight
  • Without battery and antenna - 88g
  • Without battery and with antenna - 93g
  • With battery and antenna - 125g
• Operating Temperature: 20℃ - 45℃
• Timecode Reader / Generator
  • Clock Accuracy -  0.25 PPM (1 Frame Out in 48 Hours)
  • Timecode Type -  LTC(SMPTE)
  • Timecode Frame-Rates -  23.98, 24, 25, 29.97, 29.97DF, 30, 30DF
• Internal Recording
  • Media - MicroSD Card (Flash Memory)
  • File Format - .wav BWF
  • Record Format - 24/32bit float
  • EIN - -132dBV (-130dBu) max (A-weighting, gain= 30dB, 150ohm source impedance)

NOTE: DBTX units operated inside the USA will not be able to transmit and record at the same time
