Chauvet Pro Ovation F-915FC RGBAL LED Fresnel

About: Chauvet Pro Ovation F-915FC RGBAL LED Fresnel

Ovation F-915FC is a high-power, full color mixing Fresnel style fixture that utilizes our RGBAL LED system. This fixture projects a bright beautifully soft, field of light from subtle pastels to punchy saturates and nearly any temperature of white. A motorized zoom with a 17° – 85° field range allows you to add light where it is needed. Control of the virtual color wheel, zoom and output can be via DMX or on-board dials.

• Full Color LED (RGBAL) Fresnel lighting fixture for theatre, film and production
• Soft and even field of light
• Smooth, motorized zoom from 17° to 85°
• Beautiful 16-bit dimming of master dimmer and individual colors
• Easy to use on board control of color, zoom and dimming
• Virtual Color wheel with color matched to popular gel colors
• Color Temperature Presets from 2800 K to 6500 K
• RDM (Remote Device Management) for added flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• Virtually silent operation for use in studio and theatre applications

Specifications

• Optical
  • Light Source: 89 LEDs (18 red, 18 green, 16 blue, 16 amber, 21 lime) 3 W, (1.13 A), 3698 K, 50,000 hours life expectancy
  • Color Temperature (range): 2800 to 6500 K
  • CRI (3200 K): 90
  • Beam Angle: 17° to 54°
  • Field Angle: 30° to 85°
  • Zoom Range: 17° to 85°
  • Lumens (30°): 4,294
  • Lumens (73°): 6,661
  • Illuminance (30°): 1,980 lux @ 5 m
  • Illuminance (85°): 433 lux @ 5 m
  • Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
• Dynamic Effects
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorized
  • Strobe Rate: 0 to 27 Hz
  • Standalone Color Mixing: Yes
  • Color Temperature Presets: Yes
  • Dim Modes: 4
  • Built-in Automated Programs: Yes
• Connections
  • Power Connection: Edison (Local) plug to Neutrik powerCON
  • Power Input: Neutrik powerCON
  • Power Output: Neutrik powerCON
  • Data Connectors: 3- and 5-pin XLR
  • Cable Length (power): 5 ft (1.5 m)
• Control
  • Control Protocol: DMX, RDM
  • DMX Channels: 1, 3, 5, 7, 11, 13, 14 or 17
  • Modes/Personalities: 8 personalities (1, 3, 5, 7, 11, 13, 14, 17, HSV)
• Electrical
  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 4 units @ 120 V; 8 units @ 208 V; 8 units @ 230 V
  • Power and Current: 304 W, 2.576 A @ 120 V, 60 Hz
  • Power and Current: 293 W, 1.490 A @ 208 V, 60 Hz
  • Power and Current: 293 W, 1.358 A @ 230 V, 50 Hz
• Certifications / Qualifications
  • CE, MET, FCC
  • IP Rating: IP20, dry location
  • Noise Level (Idle): 0.4 dB(A) @ 1 m
  • Noise Level (Auto): 16.8 dB(A) @ 1 m
  • Noise Level (On): 30.2 dB(A) @ 1 m
  • Noise Level (Off): 11.6 dB(A) @ 1 m
  • Noise Level (silent): 18.8 dB(A) @ 1 m
• Construction / Physical
  • Dimensions: 17.80 x 12.59 x 10.82 in (452 x 320 x 275 mm)
  • Weight: 19 lb (8.6kg)
  • Exterior Color: Black
  • Housing Material: Aluminum alloy, Aluminum die-cast
• Optional Accessories
  • Professional Clamps: CTC-50HC, CTC-50HCN
  • Neutrik powerCON cables
  • 3-pin or 5-pin DMX Cables
  • Color Blending Filters: DF60X1D, DF20D
  • Ovation F 7.5” Barndoor V2
  • Ovation Pole Operated Yoke 2 – 8”

What's Included

• Ovation F-915FC
• Neutrik powerCON power cord
• Gel frame (7.5 in/191 mm accessories)
