Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can

Model: SEVEN-PAR-7-IP

Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can
Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can
Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can
  • Free Shipping!
  •  More Coming Soon! Contact us for Lead Time
  • Not yet reviewed




About: Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can

The SEVEN PAR 7IP™ is an IP65 outdoor rated seven color par wash luminaire with (7) 25W 7-in-1 RGBAW + Lime + UV LEDs (Red, Green, Blue, White, Amber, Lime, and a 395nm UV) producing 3,600 total output lumens and 90CRI. Features include individual hue, saturation, and intensity control, RGB + seven color 3 channel DMX mode, 17° beam and 33° field angles, smooth color mixing, 12 internal programs with speed and fade control, 64 unique 7-color macros, selectable dimming curve modes, adjustable LED refresh rate and gamma brightness for flicker free operation for TV and FILM, DMX and RDM (Remote Device Management) protocol support, IP65 rated 5pin DMX and power in/out connections, dual adjustable yoke / floor stand, multiple unit power linking, OLED menu display with a 4-button control panel, a multi-voltage universal auto switching power supply (100-240v), and a rugged powder coated die-cast aluminum exterior. Gel frame and gel frame holder included, optional 4-leaf barn door available.

Features

  • IP65 Outdoor Rated Seven Color Par Wash Luminaire
  • (7) 25W 7-in-1 RGBAW + Lime + UV (395nm) LEDs
  • 3,600 Total Output Lumens | 90CRI
  • Individual Hue, Saturation, and Intensity Control
  • RGB + Seven Color 3 Channel DMX Mode
  • 17° Beam and 33° Field Angles
  • Smooth Color Mixing
  • 12 Internal Programs with Speed and Fade Control
  • 64 Unique 7-Color Macros
  • Selectable Dimming Curve Modes
  • Adjustable LED Refresh Rate + Gamma Brightness
  • Flicker Free Operation for TV and FILM
  • DMX and RDM Protocol Support
  • IP65 Rated 5pin DMX and Power In/Out
  • Dual Adjustable Yoke / Floor Stand
  • Multiple Unit Power Linking
  • Rugged Powder Coated Die-Cast Aluminum Exterior
  • Gel Frame and Gel Frame Holder Included
  • Optional 4-Leaf Barn Door Available

Specifications

SOURCE

  • (7) 25W 7-IN-1 RGBAW + Lime + UV (395nm) LEDs
  • 50,000 Hour Average LED Life*
  • *May vary depending on several factors including but not limited to:
  • Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA

  • 3,600 Total Lumen Output | 90CRI
  • 6,819 LUX 634 FC @6.6’ (2m) (Full ON)

EFFECTS

  • Individual Hue, Saturation, and Intensity Control
  • RGB + Seven Color 3 Channel DMX Mode
  • 12 Internal Program Macros with Speed and Fade Control
  • 64 Unique 7-Color Macros
  • Selectable Dimming Curve Effects

COLOR

  • RGBAW + Lime + UV (395nm)

CONTROL / CONNECTIONS

  • (7) DMX Channel Modes (15 total channels)
  • DMX and Manual Control
  • 4 Button Control Panel
  • 180° Reversible OLED Menu Display
  • Adjustable Refresh Rate (900-28,800 (Hz)
  • Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
  • RDM (Remote Device Management) Protocol Support
  • IP Rated 5pin DMX and Power In/Out
  • With Wired Digital Communication Network

SIZE / WEIGHT

  • Length: 11.24” (286mm)
  • Width: 10.71” (272mm)
  • Vertical Height: 7.36” (187mm)
  • Weight: 11.0 lbs. (5.0kg)

ELECTRICAL / THERMAL

  • AC 100-240V - 50/60Hz
  • 185W Max Power Consumption
  • 5°F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS

  • CE | IP65

UPC: 837874006896

Reviews: Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can

There are currently no product reviews.


Warranty: Elation SEVEN PAR 7IP IP65 7-in-1 LED Par Can

AVShop.ca Warranty:

30 Days

Manufacturer's Warranty:

2 Year Warranty

Elation Professional Product Rechargeable Batteries: 6 months limited
Discharge lamps and all product accessories are not covered by a warranty
