Samsung QB13C 13in HDR 16/7 Digital Signage Display

About: Samsung QB13C 13in HDR 16/7 Digital Signage Display

The newly refined QB13C delivers a slim, space-efficient design with a 13-inch display that integrates seamlessly into diverse business settings. Its intuitive usability, performance and easy management brings the essentials of business signage into compact spaces.

• Compact 13" Size & Slim Design
• Home UI
• Dual Wi-Fi (2.4GHz + 5GHz)

Compact 13" Size & Slim Design - Smaller and slimmer, greater flexibility

Slimmer frame at 19.9mm, the 13-inch compact display fits flawlessly in tight spaces, perfect for maximizing visibility without hindering performance. Its smaller design packs the same performance businesses demand, making it a smart choice for any space.

Home UI - Intuitive accessibility meets effortless usability

The QB13C features Home UI upgrades for faster, more intuitive control. Key tools such as Features, Sources, and settings are grouped for quicker access, while the Favorites folder brings you to frequently used tools in one click.

Dual Wi-Fi (2.4GHz + 5GHz) - Faster, smoother wireless performance

QB13C now supports dual-band Wi-Fi with both 2.4GHz and 5GHz frequencies, enabling faster network connections and higher data transmission speeds—especially in high-traffic areas.

SmartThings Pro - Empower your business with smart control

Samsung SmartThings now extends beyond the home with SmartThings Pro for business environments. Businesses, from small shops to large companies and hotels, can experience enhanced convenience, safety, and energy efficiency with SmartThings Pro connectivity.

Samsung VXT - Change the way to manage your display

Samsung VXT is a cloud-based solution that brings together content management and remote device management capabilities, allowing users to remotely manage hardware settings and troubleshoot issues from afar, while effortlessly creating and deploying content without the need for training.

Specifications

• Display
  • Diagonal Size: 13"
  • Panel Type: ADS
  • Resolution: 1,920 x 1,080
  • Pixel Pitch (HxV): 0.153 x 0.153 mm
  • Brightness (Typ): 500 nit
  • Contrast Ratio: 800:1
  • Viewing Angle (H/V): 170/170
  • Response Time (ms): 30ms
  • Colour Gamut: 45 %
  • Glass Haze: 25 %
  • H-Scanning Frequency: 56 - 84.5 kHz
  • Maximum Pixel Frequency: 148.5 MHz
  • V-Scanning Frequency: 48 - 75 Hz
  • Contrast Ratio (Dynamic): 10,000:1
  • Operation Time Support: 16/7
• Connectivity
  • HDMI In: 1
  • DP In: No
  • Version of HDMI: 1.4
  • Version of DP: No
  • USB: 1
  • IR In: No
  • Audio In: No
  • Audio Out: Stereo Mini Jack
  • RS232 In: Yes
  • RJ45 In: Yes
  • WiFi: Yes
  • Bluetooth: Yes
• Power
  • Power Supply: AC100-240V 50/60Hz
  • Power Consumption (On Mode): 35 W
  • Power Consumption (Sleep Mode): 0.5 W
• Operation Conditions
  • Temperature: 0 - 40 ℃
  • Humidity: 10 ~ 80%, non-condensing
• Mechanical
  • VESA Mount: 100 x 100 mm
  • Bezel Width: 12.1
  • Bezel Colour: Black
  • Frame Material: Non-Glossy
• Optional Feature
  • Mount: WMN-2090SC
  • Stand: In box (Simple Stand) (2ea)
• SoC
  • OS Version: Tizen 7.0
  • Flash Memory Size: 8GB
• Certification and Compliance
  • EMC: Class B
  • Safety: 60950-1, 62368-1
• Dimension (WxHxD): 12.68 x 7.62 x 0.78 inch (322 x 193.5 x 19.9 mm)
• Weight: 1.76 lbs (0.8 kg)
