Barco ClickShare C-5 Gen 2 One-Click Wireless Presentation for Huddle Spaces

About: Barco ClickShare C-5 Gen 2 One-Click Wireless Presentation for Huddle Spaces

The ClickShare C-5 Gen 2 brings simple, wireless collaboration to small meeting rooms and huddle spaces. You and your guests can easily share content to the room display, with just one click in the ClickShare App, from any laptop or mobile device. It offers a full BYOD experience, including screen mirroring with Airplay, GoogleCast and Miracast.

• Entry-level wireless presentation model
• Content sharing with the ClickShare App and native BYOD
• 100% secure, encrypted and cloud managed

Easy content sharing for huddle and small spaces

• Inspire and engage with wireless presentation to any screen
• Add digital signage capabilities in any huddle space
• Enhanced security, cloud managed and connected solution
• ClickShare Button sold separately

Make the most out of ClickShare

• Efficient management platform to maintain, manage and monitor your ClickShare fleet
• The right tool to increase your meeting rooms´ ROI
• Easy to stay up to date and act upon notifications
• Secure environment that keeps your data safe

SmartCare so you can be carefree

• Service package included with all ClickShare devices
• Reliable service with direct vendor support
• 5-year warranty upon registering your ClickShare devices
• 5 years of analytics and insights via XMS Cloud to optimize working spaces and increase ROI

Designed with people and planet in mind

• Made with non-paint plastics & halogen-free PCB
• Lighter, ecological packaging choices and designed for recycling
• Energy efficient to reduce your power consumption
• Carbon neutral or with a Barco ECO label: A++

Specifications

• ClickShare Base Unit dimensions
  • Dimensions (HxWxD) - 34 mm x 135 mm x 135 mm
  • Power supply - Standard 110/220 V AC plug or USB-C (only Gen2)
  • Power consumption - Operational: 5-10W, 24W Max
  • Weight - 900 gr
• General specifications
  • Operating system
    • Windows 10 and higher macOS 11 (BigSur) and higher
    • Android v9 and higher (ClickShare App)*
    • iOS 12 and higher (ClickShare App)*
  • Video outputs - 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b or USB-C DisplayPort 1.2 (only Gen2)
  • Audio output - HDMI
  • USB - 1 X USB-A, 1 X USB-C
  • ClickShare Buttons - 0
  • ClickShare App - Desktop & Mobile
  • Native protocols - Airplay, Google Cast, Miracast
  • Maximum number of simultaneous connections (with Buttons and/or App) - 32
  • Noise Level
    • Max. 25dBA @ 0-30°C
    • Max. 30dBA @ 30-40°C
  • Authentication protocol
    • WPA2-PSK in stand alone mode
    • WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
  • Wireless transmission protocol - IEEE 802.11 a/g/n/ac and IEEE 802.15.1
  • Reach
    • Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
    • Frequency band 2.4 GHZ and 5 GHz
  • Frequency band - 2.4 GHZ and 5 GHz (DFS channels supported in select number of countries)
  • Connections
    • 1x Ethernet LAN 1Gbi
    • 1x USB-C 2.0 (front); 1x USB-A 2.0 (front) - only Gen2: 1x USB-C 3.0 (front); 1x USB-A 3.0 (front)
  • Temperature range
    • Operating: 0°C to +40°C (+32°F to +104°F)
    • Max: 35°C (95°F) at 3000m
    • Storage: -20°C to +60°C (-4°F to +140°F)
  • Humidity
    • Storage: 0 to 90% relative humidity, non-condensing
    • Operation: 0 to 85% relative humidity, non-condensing
  • Anti-theft system - Kensington lock
  • Certifications - FCC/CE
  • Touch screen support & Interactivity - /
  • Room Dock (peripheral support) - No
  • Local view - Local view of the room display only
  • Network connection - LAN & WiFi
  • Management and reporting - Yes
  • Warranty - 1 year standard. 5 years coverage via SmartCare
