Sony FX5 Cinema Line Full-frame Camera (Body Only)

About: Sony FX5 Cinema Line Full-frame Camera (Body Only)

Featuring a full-frame stacked Exmor RS CMOS sensor and BIONZ XR2 with integrated AI, the FX5 combines high-speed readout and advanced image processing for an advanced movie theatre look. With 16-bit scene-linear X-OCN789 and versatile scan modes, including Open Gate3, it delivers professional operability in a compact Cinema Line body.

• Full-frame stacked Exmor RS sensor and BIONZ XR2 engine with AI processing unit
• Internal 16-bit scene-linear X-OCN recording789 for efficient post-production
• Open Gate3 plus versatile image scan modes, with up to 5K 120fps146 and 4K 240fps6 recording
• 15+ stops latitude11, three Base ISO settings and Dual Gain Shooting for flexible low-noise shooting
• Compact Cinema Line body with BIG6 (HOME) screen, 4-axis LCD and advanced monitoring support

Lighting the Way Forward
Lighting a creative path, the FX5 empowers filmmakers to step confidently into the next stage of their professional journey. Bringing an advanced movie theatre look and refined operability together in a compact body, it gives creators the freedom to realize their vision with greater precision, control and expressive potential.

5K full-frame fully-stacked Exmor RS™ CMOS sensor for speed, detail and latitude
The full-frame stacked Exmor RS CMOS sensor enables fast readout for high-resolution, high-frame-rate recording. Wide latitude and low noise ensure smooth gradation and natural textures, even in high-contrast scenes.

BIONZ XR2™ with integrated AI processing for enhanced shooting support
The BIONZ XR2 engine delivers dramatic improvements in image, sound, communication, operation and more. Built-in AI processing enables enhanced subject recognition2 and deep learning-based Auto Tracing White Balance (ATW), helping you shoot with confidence.

Open Gate3 and other image scan modes4
The FX5 offers full-frame Open Gate recording3—a first5 in the Cinema Line FX series. With 5K up to 120fps (FF 3:2)6, 4K up to 240fps (FF crop)6 and more, it gives you the freedom to adjust framing, speed and workflow to realize even the most ambitious vision.
[1] X-OCN  [2] Other codecs  [3] FPS  [4] Project Frame Rate  [5] Fixed

Internal X-OCN compressed RAW video recording
Capture 16-bit scene-linear X-OCN internally 789 eliminating the need for an external RAW data recorder. With LT, C1 and C2 codecs, you can balance image quality, file size and RAW workflow flexibility to suit the production.

Image of the codec mode menu, with X-OCN LT selected.
Example image of a vintage red car parked at an old gas station at night, next to an illuminated neon diner sign.
Three Base ISO settings for effective noise control in any environment
Three Base ISO settings—a standard ISO 800, a mid-sensitivity ISO 4000, and a high-sensitivity ISO 1280010 for low light—are available to match your shooting environment. Capture clean shadows and wide latitude across varied lighting conditions, for consistently stunning clarity.

15+ stops of latitude11 for low-noise shadow detail
Wide latitude helps capture highlight and shadow detail with smooth, natural gradation. Low shadow noise preserves clarity, texture and atmosphere, letting you push your creative grading choices further.

Dual Gain Shooting debuts in the Cinema Line FX camera series
Dual Gain Shooting maximizes latitude while reducing noise to enhance shadow details12. Making full use of the sensor’s capability, it delivers smooth, natural gradients for greater editing flexibility.

High-frame-rate capture, including 5K at up to 120fps
High frame rates open up striking slow-motion possibilities. The FX5 records up to 5K at 120fps13 and 4K at 240fps13, giving creators the power to capture fast-paced action with impressive detail and clarity—ideal for everything from cinematic storytelling to sharp sports and documentary footage.

Precise, reliable AF and tracking with AI-based subject recognition
With built-in AI processing, the BIONZ XR2 engine accurately recognizes human, animal and bird eyes (Real-time Eye AF)2. Fast Hybrid AF uses up to 759 points15 to ensure accurate focus and tracking that keeps up with quick-moving subjects, even in dark scenes and when shooting with a shallow depth of field.

Built-in de-squeeze for anamorphic shooting
Built-in de-squeeze support makes anamorphic shooting easier on set. With 1.3x, 1.5x, 1.6x, 1.8x and 2.0x settings, the FX5 works smoothly with a wide range of anamorphic lenses.

Deep learning-based illumination estimation
Deep-learning-based illumination estimation achieves unprecedented Auto Tracing White Balance (ATW) accuracy, even in challenging scenes. It delivers accurate colour reproduction even under lighting conditions that previously tended to cause colour cast.

S-Cinetone™ for a refined cinematic look
S-Cinetone brings Sony cinema colour science to the FX5, delivering natural skin tones, smooth gradation and a polished look straight out of camera.

Wide-gamut colour for more grading control
With colour gamuts exceeding both BT.2020 and DCI-P3, S-Gamut3 and S-Gamut3.Cine retain broad colour information for more precise grading and easier colour matching with VENICE 2 in multi-camera shoots.

Three S-Log3 modes for flexible workflows
From cinematic shoots to run-and-gun, choose Cine EI, Cine EI Quick or Flexible ISO16 to capture imagery with maximum latitude. You can also import up to 16 user LUTs17 allowing you to easily monitor the intended look in real-time.

5-axis stabilization for steadier handheld shooting
A precision stabilization unit and gyro sensors combine to provide optical 5-axis in-body stabilization. An enhanced stabilization unit expands the roll-direction compensation range by up to 2x, effectively reducing handheld roll shake18. The result is a camera that’s ideal for handheld shooting. Dynamic active Mode19 adds extra electronic support, and stabilization data can also be used in post-production20.

Lightweight, compact design for agility on set
The compact flattop body and stable grip are built for comfortable handheld work. Paired with Sony’s compact lenses, the FX5 becomes a mobile system for flexible shooting with gimbals, in tight spaces and more.

High-quality 96 kHz / 32bit float audio recording
The XLR handle unit21 supports two XLR/TRS inputs, a 3.5 mm stereo mini jack and up to 96 kHz / 32bit float audio. With up to 4 channels of top-quality audio recording, it helps you capture cleaner sound without slowing down the shoot.

BIG6 (HOME) screen for faster on-set control
Inherited directly from Sony’s high-end CineAlta cameras, the BIG6 (HOME) screen displays six essential settings together: frame rate, EI/ISO/Gain, shutter, iris, LUT and white balance. Touch operation, the multi-function dial and Fixed/Variable frame-rate control help you work quickly and efficiently.

Optional OLED viewfinder DVF-EL1 for easier outdoor monitoring
Add the optional OLED viewfinder22 for enhanced monitoring in bright locations. It features a 0.58-type OLED panel with approx. 7.07 million dots, DCI-P3 equivalent colour gamut, and 10-bit display for superb colour and detail.

Monitoring support for precise shooting
Exposure and focus tools, including Waveform Monitor, Histogram, False Colour and Focus Map, support faster judgments on set. They help you manage highlights, shadows, skin tones and critical focus with confidence.23

Clear Image Zoom for smoother, more intuitive framing
Clear Image Zoom adds a [Smooth Priority] mode24 that enables seamless zoom from the optical wide end up to 2x digital zoom25. [Optical Zoom Priority] is a zoom mode that prioritizes image quality. After the optical zoom reaches its telephoto end, Clear Image Zoom takes over.

Dual CFexpress Type A/SD card slots for flexible media workflows
Dual CFexpress Type A slots26 support relay, simultaneous and separated recording, and they also accept SDXC (UHS-II/UHS-I) cards. Main and proxy files can be recorded to different slots.

Power that keeps pace with long shoots
A high-capacity 2670 mAh NP-SA10027 battery can provide up to 170 minutes28 of recording time. Optimized power management, faster charging29, USB Power Delivery (PD)30 and battery condition display make day-to-day operation easier.

Cooling designed for uninterrupted 170 minutes of recording
An efficient fan cooling system and advanced design help keep the camera cool, even when the LCD monitor is closed. Three fan modes—[Auto], [Minimum] and [OFF in REC]—let you balance cooling and noise to suit your shooting needs.
