Tilta Full Camera Cage for BMCC 6K - Basic Kit

About: Tilta Full Camera Cage for BMCC 6K - Basic Kit

Introducing the redesigned Basic Camera Cage Kit for the Blackmagic Cinema Camera 6K!

The foundation of this Camera Cage for the BMCC 6K (Full Frame) provides protective armor for the camera body and allows users to secure different accessories to improve the camera’s functionality.

This updated version features a top plate that perfectly aligns with the 1/4″-20 thread on the top of the Full Frame camera body which is not currently compatible with our previous version of this cage.

The new design also feature two screws to connect the cage to the bottom of the camera which creates an incredibly secure three points of contact.

The Full Cage offers several 1/4”-20 threads with locating points, cold shoe receivers, an Arri compatible rosette and a NATO Rail for NATO based Side Handles and accessories.

The right side arm module can be removed to turn this Full Cage into a Half Cage, which offers more flexibility in situations where lighter builds are required, such as when using a gimbal.

The Bottom Plate provides several 1/4″-20 mounting points for attaching your camera to various quick release plates and is compatible with the ARCA Receiver of the DJI RS3 Pro.

When using the Half Cage, the bottom plate can be extended to support the Black Magic Design Battery Grip and includes a 15mm Rod Holder to use rod based accessories in the correct LWS alignment with the Battery Grip.

Included in the Basic Kit is the Xeno Top Handle which mounts to the cage via a 1/4″-20 screw with locating pins.

The handle features a silicone padded grip, which makes handling more comfortable while featuring numerous mounting points for additional accessories such as a cold shoe receiver, 1/4″-20 and 3/8″-16 threads.

The included 90 Degree HDMI Adapter attaches to the cage near the HDMI port which offers a secure connection that limits wear on the port.

The kit also includes an SSD Drive Holder that mounts via a 1/4″-20 screw with a locating pin, and allows users to clamp down on a Samsung T5 SSD drive for external recording.

Features

• PROTECTIVE ARMOR - for BMCC 6K Protects Camera & Minimizes Wear Over Time
• MOUNT ACCESSORIES - via NATO Rail, Arri Compatible Rosette, Cold Shoe Receivers, 1/4"-20 Threads with Locating Pins
• VARIOUS CONFIGURATIONS - via Detachable Design Allows for Half Cage & L-Bracket Setups
• XENO TOP HANDLE - Provides Additional Mounting Points & Increased Flexibility When Operating or Handling
• BATTERY GRIP - Compatible via an Adjustable Bottom Plate Expansion Bracket and Dual 15mm Rod Holder

Specifications

• Materials: Aluminum alloy, stainless steel
• Color: Black
• Dimensions: 11.4x 9 x 4.3 inches
• Weight: 2.5 lbs

What's in the Box

• Full Camera Cage for BMCC 6K – Black
• Tilta Xeno Top Handle (1/4″”-20 with Locating Pins) – Black
• Tilta SSD Drive Holder for T5 – Black
• 15mm Rod Holder for BMPCC 6K Pro – Black
• HDMI 90-Degree Adapter for BMPCC 4K/6K

NOTE: Camera Cage (Basic Kit) only, camera not included.
