LD Systems ICOA 12-Inch Powered Coaxial PA Loudspeaker

About: LD Systems ICOA 12-Inch Powered Coaxial PA Loudspeaker

This full-range loudspeaker impresses with its outstanding sound, even at low frequencies. The ICOA 12 A by LD Systems is a genuine all-rounder that offers unparalleled features for its class. Its coaxial design, rotating, BEM-optimised CD horn and extensive and precisely calibrated DynX DSP presets make this powered 12" loudspeaker exceptionally flexible.

• A genuine all-rounder for full-range, satellite and monitor applications
• 126 dB max. SPL and 1200 W peak power
• Vertical and horizontal use thanks to coaxial design with rotating, BEM-optimised CD horn (Patent pending)
• Horn-loaded woofer
• DynX DSP with 4 presets, 3-band EQ and delay function
• 2 line/mic input channels with individual gain controllers plus mono mix output; Bluetooth® streaming with the BT model
• 36 mm dual tilt stand attachment with 0° and 5° tilt angle, 55° monitor angle with sturdy stand
• 6 x M10 flying points
• Shock-resistant front grille for optimal protection of the speaker
• 4 aluminium grips with ergonomic, rubber surface
• Extensive, optionally available accessories for installation and transport

The outstanding bass reproduction from the horn-loaded woofer makes the LD ICOA 12 A the ideal choice for musicians, bands, entertainers and dance schools. It also allows DJs to play sets without the need for a subwoofer. Deployed vertically, the speaker impresses as a satellite; horizontally, it's excellent in suspended systems or as a floor monitor. The efficient class-D power amplifier delivers 126 dB max. SPL and 1200 W peak performance.

Drawing on DynX DSP technology by LD Systems, the speaker delivers perfect performance with maximum clarity and power under all conditions. 4 presets, a 3-band EQ and a delay function facilitate optimal adjustment of the sound to the venue conditions. The 2 line/mic input channels with individual gain controllers, plus mono mix output, allow a variety of signal sources to be connected.

Thanks to its shock-resistant front grille and ideal 55° tilt angle, the LD ICOA 12 A is also outstanding as a floor monitor. Placed vertically, the 36 mm dual tilt stand attachment offers the choice of a 0° or 5° tilt angle for optimally adapting the system to the local acoustic environment.

Extensive and smart accessories for installation and transport are optionally available. 4 aluminium handles with an ergonomic rubber surface provide optimal grip when carrying the speaker.

Specifications

• Product type - PA loudspeaker
• Type - Powered
• Low/mid Woofer dimensions - 12" (304.8 mm)
• Woofer magnet - Ferrite
• Woofer brand - Custom-made
• Horn - BEM optimized CD Horn
• HF driver dimensions - 1" (25.4 mm)
• HF driver magnet - Ferrite
• HF driver brand - Custom-made
• HF driver voice coil - 1.4" (35 mm)
• Amplifier - Class D
• Dispersion (H x V) - 90° x 50°
• System Power (RMS) - 300 W
• Peak power - 1200 W
• Frequency response - 50 Hz - 20000 Hz
• Crossover frequency kHz - 2 kHz
• Max. SPL (Peak) - 126 dB
• Protection circuits - Multiband limiter, over voltage, over-current, thermal overload
• Controls - 2 x gain, On / off switch, Rotary/push encoder
• Indicators - LC display
• Mic/ line inputs - 2
• Mic-/ Line Input Connectors - 6.3 mm jack Combination sockets (symmetrical), XLR
• Line inputs - 1
• Line input connectors - 3.5 mm TRS
• Line outputs - 1
• Line output connectors - XLR
• Operating voltage - SMPS
• Power consumption - 150 W
• Ambient temperature (in operation) - 0 - 40 °C
• Operating voltage - 100 V - 240 V AC / 50 - 60 Hz
• Relative Humidity - < 80 %, not condensing
• Fuse - T4AL 250 V
• Cabinet material - Polypropylene
• Cabinet construction - Bass Reflex
• Mounting - 36mm flange (0°, 5°), 6 x M10 flying points
• Monitor angle - 55 °
• Dimensions (WxHxD) - 14.76 x 25 x 15.59 inch (375 x 635 x 396 mm)
• Weight - 43.98 lbs (19.95 kg)
• Accessories (included) - Power cord
