Klipsch Full-Range 8" Professional Surface Mount Loudspeaker - White (Each)

About: Klipsch Full-Range 8" Professional Surface Mount Loudspeaker - White (Each)

PROFESSIONAL SURFACE MOUNT SPEAKERS

Featuring the newly-developed Tractirx Hyperfold Port this updated line of Professional Surface Mount speakers boasts more bass output and greater dispersion from a smaller enclosure. The PSM Series' IPX6 Rating means you can install these even in the most challenging commercial environments. Combined with Legendary Klipsch sound and all the familiar but updated features you’re used to, this line of speakers is perfection for your pro needs.

• More bass, less space with the all-new Tractrix Hyperfold Port
• 1” Titanium Compression Driver for effortless, high-clarity detail
• IPX6 Rated for even the most challenging commercial environments
• Multi-tap transformer for 70 or 100 volt installations, includes bypass position
• Set screws on grille
• Phoenix Connector for simplified installation
• Paintable, rust-proof aluminum grille

IPX6 WATERPROOF PROTECTION - READY FOR INDOOR/OUTDOOR COMMERCIAL ENVIRONMENTS

Perfect for indoor and outdoor commercial installations around the globe, the Klipsch PSM Series is IPX6 Rated. Your clients will rest easy knowing their new speakers will be water-resistant and rainproof for the most challenging commercial environments.

ALL-NEW TRACTRIX HYPERFOLD PORT - MORE BASS, LESS SPACE

Klipsch is all about high efficiency, low distortion. Building upon that legacy, we’re introducing the all-new patented Tractrix Hyperfold Port engineered to extend port length for maximum bass power via proprietary five-step folded design. Its increased airflow eliminates chuffing and port noise while providing a greater dispersion pattern for larger coverage areas.

PAINTABLE UV-RESISTANT ABS ENCLOSURE - WITH RUSTPROOF ALUMINUM GRILLE

Need a different color for your project? These professional surface mounted speakers are made to be fully customizable with paintable rustproof grilles.

MULTIPLE TAP SETTINGS & PHOENIX CONNECTOR - FOR VARYING AND SIMPLIFIED INSTALLATION

These professional surface mounted speakers include a multi-tap transformer for 70 or 100 volt installations. There’s also a bypass position allowing normal 8 ohm operation for installations that don’t require a transformer. The PSM Series also employs a phoenix connector for quick and intuitive connection.

SET SCREWS ON GRILLE - ENSURING A SECURE FIT

The included set screws on each grille ensures a secure fit between the speaker and grille, while making sure the grilles stay on the enclosures regardless of the environment.

1” TITANIUM COMPRESSION DRIVER - FOR EFFORTLESS, HIGH-CLARITY DETAIL

Klipsch outperforms the competition with our all-new 1” Titanium-loaded floating driver bridge with wide dispersion phase plug. Using our patented mumps technology, these professional surface mounted speakers give any space extra-wide coverage while providing even and consistent energy for your project.

SPECIFICATIONS

• FREQUENCY RESPONSE - 52Hz-20kHz +/- 4dB, 44Hz -10dB
• POWER HANDLING - 100 watts (21V) 50Hz-10kHz (400 watts peak)
• CALC. MAX. CONT. OUTPUT - 109dB
• SENSITIVITY - 92dB
• COVERAGE - 100° +/- 20° 1kHz-20kHz
• DIRECTIVITY INDEX - 7dB+/-1.5dB 800Hz-20kHz
• NOMINAL IMPEDANCE - 8 ohms 4.2 ohms at 150Hz minimum
• ACOUSTIC CROSSOVER - 2kHz
• TRANSDUCERS
  • 8” woofer
  • 1” titanium compression driver, on a K-1200M horn/tweeter bridge
• ENCLOSURE MATERIAL - All Weather ABS Plastic, Paintable
• IP RATING - IPX6
• ENCLOSURE TUNING - Vented via 3 folded Tractrix ports
• INPUT CONNECTORS - 4 pin euro block
• TRANSFORMER TAPS
  • 70V: 100W, 50W, 25W,12.5W
  • 100V: 100W, 50W, 25W
  • Bypass position: 8 ohms nominal
• DIMENSIONS [WITH BRACKET] - 15.5”(394mm) x 12”(305mm) x 9.31”(237mm) [11.12”(283mm)]
• WEIGHT - 15.75 lbs (7.15kg)
