Fender Quantum HD 2 USB-C Audio Interface

About: Fender Quantum HD 2 USB-C Audio Interface

The Fender Quantum HD 2 is a 20 x 24 USB-C interface designed for musicians, producers, and project studios who demand accuracy, clarity, and flexibility. Featuring next-generation MAX-HD mic preamps, ultra-low-latency drivers, and high-performance converters, the HD 2 captures every nuance of vocals, guitars, bass, and full-band sessions with professional precision.

• Ultra-High-Fidelity 20 x 24 USB-C Interface – MAX-HD preamps, 32-bit / 192 kHz converters, and low-noise signal flow for pristine audio capture.
• MAX-HD Mic Preamps with +75 dB Gain – Transparent, professional-quality recordings for any microphone.
• Expanded Digital I/O – 16 ADAT channels and S/PDIF I/O.
• Fender Instrument Inputs – Front-facing inputs optimized for guitars and bass for plug-and-play clarity.
• Auto Gain & Re-Amp Outputs – Hassle-free level setting and creative amp/pedal experimentation.
• DSP Monitor Mixer & Loopback – Stream, podcast, or create monitor mixes with ease.
• Universal Control & Studio Pro Integration – Adjust preamp gain, phantom power, and routing from mobile, desktop, or DAW.
• Professional Software Included – Fender Studio Pro perpetual license.

Front-facing Fender instrument inputs provide transparent, studio-ready recordings for guitar and bass, while Auto Gain simplifies setup and re-amp outputs allow tonal experimentation without extra takes. Integrated DSP monitor mixing and loopback routing streamline streaming, podcasting, and recording workflows.

Control preamp gain, phantom power, and monitoring remotely via the Fender Studio Pro or Universal Control app for seamless integration. Ideal for project studios, the Fender Quantum HD 2 balances compact size with professional-grade I/O.

ULTRA-HIGH-FIDELITY RECORDING

MAX-HD preamps and high-performance converters deliver pristine audio with stunning clarity.

FENDER INSTRUMENT INPUTS

Front-facing inputs ensure guitars and basses translate perfectly to your mix.

OPTIMIZED WORKFLOW

Auto Gain, re-amp outputs, DSP monitor mixer, and loopback routing streamline recording and streaming.

SEAMLESS SOFTWARE INTEGRATION

Full control from Fender Studio Pro or Universal Control app keeps your workflow smooth and intuitive.

Specifications

• AD / DA CONVERSION
  • Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz
  • Bit Depth: 32-bit
• INPUTS
  • Instrument Inputs
    • Connector Type: 1/4-inch Female
    • Gain Range: -7 dB to +68 dB
    • Maximum Input Level: +21 dBu (unbalanced, minimum gain)
    • Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
    • Dynamic Range: 121 dB (A-weighted, typical)
    • THD + N: 0.0003% (1 kHz, minimum gain)
    • Input Impedance: 1M Ohms
  • Microphone Inputs
    • Connector Type Combo-style, XLR / TRS (digital control, +75 dB mic range)
    • Maximum Input Level: +18 dBu (balanced, minimum gain)
    • Gain Range: 0 to +75 dB
    • Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
    • Dynamic Range: 121 dB (A-weighted, typical)
    • THD + N: 0.002% (1 kHz, minimum gain)
    • EIN: -130 dBu (max gain, 150 Ohms, 20 kHz BW, A-weighted)
    • Input Impedance: 1,600 Ohms
  • Line Inputs
    • Connector Type: Combo-style, XLR / TRS
    • Maximum Input Level: +18 dBu (balanced, minimum gain)
    • Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (unity gain, reference 1 kHz)
    • Dynamic Range: 121 dB (A-weighted, typical)
    • THD + N: 0.001% (1 kHz, minimum gain)
    • Input Impedance: 10K Ohms
    • Digital Trim: -12 to +12 dB
• OUTPUTS
  • Main Outputs
    • Connector Type: 1/4-inch Female, TRS
    • Maximum Output Level: +18 dBu
    • Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (unity gain, reference 1 kHz)
    • Dynamic Range: 125 dB (A-weighted, typical)
    • THD + N: 0.001% (1 kHz, +4 dBu)
    • Output Impedance: 51 Ohms
    • Trim Range: -∞ dB to 0 dB
  • Line Outputs
    • Connector Type: 1/4-inch Female, TRS
    • Maximum Output Level: +18 dBu
    • Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (unity gain, reference 1 kHz)
    • Dynamic Range: 125 dB (A-weighted, typical)
    • THD + N: 0.001% (1 kHz, +4 dBu)
    • Output Impedance: 51 Ohms
  • Re-Amp Outputs
    • Connector Type: 1/4-inch Female, TS
    • Maximum Output Level: +4 dBu (Balanced)
    • Frequency Response: 20 Hz to 20 kHz, +/- 0.3 dB (unity gain, reference 1 kHz)
    • Dynamic Range: 117 dB (A-weighted)
    • THD + N: 0.001% (1 kHz, +4 dBu)
    • Output Impedance: 100 Ohms
    • Trim Range: -∞ dB to 0 dB
  • Headphone Outputs
    • Connector Type 1/4-inch Female, TRS (1-4)
    • Maximum Output Level 11 dBu (50 Ohms)
    • Frequency Range 20 Hz to 20 kHz, +/- 0.3 dB (unity gain, reference 1 kHz)
    • Dynamic Range 118 dB (A-weighted)
    • THD + N 0.001% (1 kHz)
    • Output Impedance 33 Ohms
    • Trim Range -∞ dB to 0 dB
• DIGITAL I/O
  • S/PDIF I/O
    • Connector Type: Phono RCA (1 in , 1 out)
    • Supported Sample Rates (kHz): 44.1, 48, 88.2, 96
  • ADAT I/O
    • Connector Type: Optical TOSLINK (2 in, 2 out)
    • Format
      • ADAT Digital Lightpipe with S/MUX II
      • 16 channels at 44.1/48 kHz
      • 8 channels at 88.2/96 kHz
  • MIDI I/O
    • Connector Type: 5-pin DIN (off DB-9)
• POWER
  • Connector Type: DC Connector
  • Configuration: External, Universal​
  • Power Input: 12V DC, 2A
• Dimensions (HxDxW): 1.9 x 8.5 x 7.5 inch (48.3 x 215.9 x 190.5 mm)
• Weight: 2.9 lbs (1.32 kg)

What's in the Box

• Quantum HD 2 Audio Interface
• USB-C to USB-C cable (1.5m)
• DB9 Breakout Cable for MIDI and S/PDIF
• Power Supply Unit
• Quick Start Guide
• Health, Safety and Compliance Guide
