Antelope Audio Orion Studio Synergy Core

About: Antelope Audio Orion Studio Synergy Core

Orion Studio Synergy Core is already a modern classic in top-tier studio equipment. Its unmatched high-resolution sound, flexible digital control, and ever-evolving library of flawlessly modeled audio effects make it a top choice for any recording and production-oriented studio. The generous and expandable I/O count, combined with its support for the Antelope Audio Atmos-ready system, makes the unit the top choice for immersive and surround sound setups of all sizes.

Key Features

• Analog & Digital Connectivity
  • 14 x 24 Rackmount audio interface with Thunderbolt & USB connection for Mac/Windows;
  • 12 Discrete ultra-linear preamps with 75dB of gain on combo XLR jacks for studio-quality recordings. All work as microphone/line/Direct-In inputs, and four of them are Hi-Z compatible. All preamps are fully DC-coupled;
  • Two analog inserts (applied to preamp 1 and 2) to connect analog gear without the need to do additional routing in the DAW or in the control panel;
  • 16 DC-coupled analog output channels over a D-Sub 25 connector allowing control of modular synthesizers;
  • Two reamp outputs on TRS ¼ jacks for further amp processing of guitar signal;
  • Thunderbolt 3 (up to 32 channels) and USB 2.0 (up to 24 channels) ports for native DAW application with custom macOS & Windows drivers;
  • Digitally expandable over ADAT (up to 16 channels) and SPDIF (up to 2 channels);
  • Two stereo headphone outputs;
  • Two monitor outputs that can work both in parallel or in A/B mode.
• Clocking & Conversion
  • Proprietary 64-bit Acoustically Focused Clocking technology for increased width, separation, and detail in musical performances;
  • Proprietary Jitter Management algorithm delivering truthful and expanded soundstage;
  • High-resolution A/D and D/A conversion ensuring artefact-free recordings and mastering-grade converter with 130dB headroom for critical listening without coloration or signal degradation.
• Real-Time Effects Processing
  • Collection of 50 analog-modeled effects featuring classic as well as rarely emulated compressors, EQs, mic preamps, and guitar amps and cabs;
  • 6×DSP, 2×FPGA Synergy Core proprietary onboard real-time platform for effects processing with imperceptible latency;
  • Up to 128 effects instances per session loaded simultaneously on 32 individual virtual racks.
• Workflow-Enhancing Features
  • Advanced digital Routing Matrix that allows execution of complicated input/output routing with a simple drag and drop functionality;
  • 4 mixers with 32 channels each for creating individual cue mixes and sub-mixes, allowing you to distribute headphone mixes for your musicians while applying pan, reverb, other effects and stereo link;
  • Customizable presets complete with signal routing, level adjustments, mixer settings and sub-mixes;
  • Direct hardware monitoring with effects, processed in real-time with imperceptible latency;
  • Direct-In function allowing you to bypass the preamp architecture and record directly through the converter;
  • Fully DC-coupled I/O to control and receive CV from modular synths;
  • Easily accessible talkback with built-in microphone;
  • Front panel with volume knob with selectable sources and functional buttons;
  • Option to work without being connected to a computer (standalone operation);
  • Wireless control of software features from a separate computer connected to the same network.​

SONIC TRANSPARENCY

The 12 discrete preamps of the Orion Studio Synergy core are among its most signature features. Designed to remain transparent while authentically capturing any sound source, they provide the stunning 75 dB of gain while keeping noise at a practically non-existent level. The Orion Studio mic preamps excel at capturing the true character of vocals or any acoustic instrument. They shine the brightest, especially when paired with the Antelope Audio Edge modeling condenser microphones.

MAXIMUM ANALOG POTENTIAL

• DIRECT LINE INPUTS: The Direct-In feature of all Orion Studio analog inputs allows you to bypass the preamp controls and directly record line-in signals without any coloration.
• SYNTHS’ BEST FRIEND: Control your CV-compatible synths and outboard gear with the Orion Studio DC-Coupled inputs and outputs.
• SEND AND RETURN: Two analog inserts (applied to Preamp 1 and 2) allow you to connect analog outboard gear without additional routing in the DAW or the Control Panel.

ATMOS-READY: EMBRACE THE FUTURE OF AUDIO PRODUCTION

Orion Studio Synergy Core is fully compatible with our Atmos-Ready surround and immersive audio monitoring system. It offers precise speaker and room calibration tools as well as intuitive monitoring controls with fast preset save and recall. Designed to increase productivity and enhance your workflow, the system is compatible with over 23 audio formats from stereo to Dolby Atmos 9.1.6.

• * The Surround tab functionality gets unlocked upon activating the MRC remote controller.

TACTILE POWER

The MRC controller is the physical extension of the Atmos-Ready surround and immersive system. The Orion Studio Synergy Core-compatible hardware unit was designed to provide streamlined and tactile controls for effortless and advanced monitoring.

EXPLORE 50+ LEGENDARY AUDIO EFFECTS

Orion Studio comes packed with an exclusive selection of audio effects, modelled after iconic, rare, and sought-after studio hardware. Crafted with meticulous precision and care, the effects are powered by our proprietary Synergy Core platform. All processing is handled by the interface itself, ensuring the most authentic recreation of the real hardware as well as zero-latency performance.

IMMENSE ANALOG & DIGITAL FLEXIBILITY

There is no task the Orion Studio Synergy Core can’t handle. Record high-impedance instruments and reamp DI tracks through the designated Reamp outputs. Use in various multichannel setups or connect all of your outboard gear via the unit’s 16 line outputs. Expand your I/O count through the digital S/PDIF and ADAT ports. Use the intuitive and flexible software Routing Matrix to freely direct all incoming and outgoing audio signals. A handy addition to the already massive Orion Studio monitoring potential are the two headphone and monitor outs, which can be used simultaneously.

What's in the Box

• Orion Studio Synergy Core Interface
• Quick Start Guide
• Inline External Power Supply Unit
• USB Cable
