Chauvet Pro Maverick Force X Spot Moving Head LED

About: Chauvet Pro Maverick Force X Spot Moving Head LED

This powerful yet lightweight fixture combines the latest technical advancements of the Maverick series to achieve 17,325 lumens of output in a design that maintains a flat field of focus from its narrow 3.5° beam to its wide 57.7° beam. Color calibration and gobo selection are comparable to other Force fixtures, and its design includes a variable CMY color mixing system, renowned for its true reds, a color wheel with CRI and CTB filters, static and rotating gobo wheels, a five-facet prism, iris, and frost. With excellent dimming performance, a wide 18:1 zoom, and a comprehensive array of features, the Maverick Force X Spot is a compact LED moving head, ideal for a wide range of short- and long-throw applications. Control via DMX, RDM, sACN, Art-Net, or CRMX.

• Compact LED Spot Fixture: A fully-featured, lightweight 520W LED yoke spot fixture with a comprehensive set of professional tools.
• Variable CMY Color Mixing: Create a vast spectrum of colors with the smooth, variable CMY color mixing system.
• Dual Gobo Wheels: Includes one rotating and one static gobo wheel for a wide range of pattern and aerial effects.
• 16-Bit Dimming: Provides exceptionally smooth control of fades and intensity changes.
• High-Speed PWM: A 65,000 Hz PWM rate ensures flicker-free operation on camera while maintaining excellent dimming.
• Flexible Control Options: Supports DMX, WDMX, sACN, and Art-Net protocols for versatile integration into any control system.
• RDM Enabled: Allows for remote addressing, configuration, and troubleshooting directly from your controller.
• Wide Zoom Range: Offers an expansive 3.5° to 57.7° zoom range for creating variable beam sizes.
• Advanced Beam Control: Shape and modify the beam using the built-in iris, 5-facet prism, and frost filter.
• True-1 Power Input: Features a secure, True-1 compatible power input connection for reliable power.
• Easy Setup Presets: Simplify shop preparation with three menu presets and the ability to sync settings across multiple fixtures.
• USB Software Updates: A convenient USB slot allows for quick and easy software uploads to keep the fixture current.
• Battery Powered Display: Access the menu without main power via a display that auto-rotates for easy viewing in any orientation.
• Failsafe Ethernet Connectivity: Ensures data pass-through continues on the network line even if the fixture loses power.
• NFC Fixture Setup: Utilize Near Field Communication for fast and easy fixture configuration directly from a compatible device.

Specifications

• Optical
  • Light Source: 1 LED (CW) 520 W, (4.2 A), 6462 K, 50,000
  • Color Temperature (at full): 6462 K
  • Front lens diameters: 145 mm
  • CRI: 72.2
  • CQS: 69.6
  • TLCI: 50
  • CRI with CRI filter: 90
  • CQS with CRI filter: 89.8
  • TLCI with CRI filter: 78
  • CTB color temperature: 7946K
  • Beam Angle: 3.5° to 51.3°
  • Field Angle: 3.7° to 56.3°
  • Cutoff Angle: 3.9° to 57.7°
  • Zoom Range: 3.5° to 57.7°
  • Lumens – Output: 17,325
  • Illuminance (3.5°): 93,084 lux @ 5 m
  • Illuminance (57.7°): 1,135 lux @ 5 m
  • Selectables PWM: 600Hz, 1500Hz, 2000Hz 65000Hz
• Dynamic Effects
  • Pan and Tilt: 540°/270°
  • Pan and Tilt ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colors: Colors: 7 (Red, Orange, Magenta, CTO 4300K, CTO 3200K,  CRI and CTB filters) + white, split colors, continuous scroll at variable speeds
  • Colors: CMY wheels
  • Color Macros: # macros
  • Gobos:
    • Gobo (1): 7 + open (1 metal + 6 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
    • Gobo (2): 9+ open (9 metal) continuous scroll at variable speeds
  • Gobo Size: Gobo Wheel 1 (rotating): 24 mm (outside), 14 mm (image), 1.1 mm (max. thickness)
  • Dimmer: Electronic
  • Shutter/Strobo: Electronic
  • Zoom: Motorized
  • Focus: Motorized
  • Frost: Motorized
  • Iris: Motorized
  • Prism: 5-facet, motorized, rotating
  • Strobe Rate: 0 to 25 Hz
  • Move-in-Black: yes
  • Dim Curves: 5
• ​Connections
  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Power Output: Seetronic Powerkon IP65
  • Data Connectors: 3- and 5-pin IP65 XLR, Seetronic etherCON
  • Cable Length (signal): 5 ft (1.5 m)
• Control
  • DMX Channels: 22 or 29
  • Art-Net Channels: 22 or 29
  • Modoes/Personalities: 2 personalities (22, 29)
• Electrical
  • Input Voltage: 100 a 240 VAC, 50/60 Hz
  • Power Linking: 2 units @ 120 V; 4 units @ 208 V; 5 units @ 230 V
  • Power and Current: 554 W, 4.64 A @ 120 V, 60 Hz
  • Power and Current: 541 W, 2.68 A @ 208 V, 60 Hz
  • Power and Current: 542 W, 2.44 A @ 230 V, 50 Hz
• Battery
  • Battery type: Lithium Ion (display screen backup)
  • Rechargeable: Yes
  • Battery Charge Time: 5 hours
  • Battery Life: 1 hour
  • Battery Power: 3.7 V, 500 mAh
• Certifications/Qualifications
  • Certifications: CE, MET, FCC, UKCA
  • IP Rating: IP20, dry location
  • Noise Levels
    • Noise Level (Idle): 33.6 dB(A) @ 1 m
    • Noise Level (Auto): 36.6 dB(A) @ 1 m
    • Noise Level (Full): 39.7 dB(A) @ 1 m
    • Noise Level (ECO): 34.5 dB(A) @ 1 m
    • Noise Level (TV25): 34.5 dB(A) @ 1 m
    • Noise Level (TV35): 34.5 dB(A) @ 1 m
    • Noise Level (max): 42.4 dB(A) @ 1 m
  • Temperature (Ambient): -4 °F to 113 °F ( -20 °C a 45 °C )
• Construction/Physical
  • Housing Material: Aluminum die-cast, High-impact flame-retardant polymer, Steel
  • Exterior Color: Black
  • Dimensions: 14.21 x 9.41 x 25.43 in (361 x 239 x 646 mm)
  • Weight: 44.1 lbs (20 kg)

What's Included

• Maverick Force X Spot
• Seetronic Powerkon power cable
• Omega brackets with mounting accessories
