Ape Labs Neon Tube PIX - Solo

About: Ape Labs Neon Tube PIX - Solo

More control. More possibilities. The Neon Tube PIX offers 32 individually controllable LED segments for dynamic color gradients, effects, and creative staging – directly controllable via app, remote control, or DMX.

Ideal for shows, stages and installations where movement and play of colors are the focus.

• Battery-powered LED tube 100 cm long for indoor & outdoor weatherproof
• Bright, flexible battery-powered light tube with 96 LEDs and 32 individually controllable pixels
• Multipixel presets controllable via app & remote control
• Flexible attachment via neodymium magnet
• 5 x M6 threads on the end caps for versatile mounting options
• M6 safety eyelet included
• Optional Truss clamp adapter for truss mounting available as an accessory (Art. No. 100123)
• Homogeneous light image without visible pixels
• Tripod stand available as an accessory for vertical setup
• Battery operation or continuous operation on mains power possible
• Battery life approx. 15 hours
• Beam angle 180 °
• Controllable via Ape Labs remote control, smartphone app and wireless DMX (via CONNECT or CRMX)
• Flicker-free LED control (>2 kHz) – ideal for TV and film recordings
• RGB + Warm White (2700K) LED color combination
• CRI 90 for natural color rendering
• DMX modes: 4ch, 7ch, 32ch, 128ch (for 32-pixel control)
• Automatic signal repeater between devices (up to 1200 m)
• Music mode, pairing, cloud-based storage of lamp settings
• Free software updates via CONNECT and app
• Made in Germany

Easy Handling

Controlling the Ape Labs Neon Tube PIX is incredibly easy: With the iOS & Android app, the remote control, or wireless DMX, you always have full control. All lamps can also be securely networked to prevent unauthorized access. Even without the app, the colors can be changed directly on the lamp – for maximum flexibility and ease of use.

Long Battery life

With a battery life of up to 15 hours, the Ape Labs Neon Tube PIX is a true long-distance runner. If you need to run longer, the brightness can be easily adjusted via a smartphone app to extend the runtime. Even when continuously powered by mains power, the Neon Tube PIX remains reliable, providing even, flicker-free light.

Diverse Applications

Whether in the hospitality industry, at events, or in a TV studio – the Ape Labs Neon Tube PIX is versatile and meets the highest professional requirements. Thanks to its compact dimensions (100 cm long, 40 mm diameter), it blends seamlessly into any environment. Mounting options are flexible: upright, via neodymium magnet, on trusses, or on a tripod stand – there's a suitable solution for every creative idea.

Specifications

• Electricity
  • Lamp charging voltage: 16 – 19 V
  • Lamp operating voltage: 12 V
  • Battery type in lamp: Ni-MH 43,2 Wh
  • Current consumption when charging: approx. 1 A
• Control / Operation
  • 4 group management via remote control, smartphone app or 4 DMX universes
  • Automatic signal repeater from lamp to lamp (approx. 1200 m)
  • (Optional) Remote control (approx. 50 meter range)
  • Smartphone app for iOS & Android via (optional) CONNECT (approx. 1200 meters range)
  • Wireless DMX via (optional) CONNECT (approx. 1200 meter range)
  • KNX control via (optional) CONNECT
• DMX
  • 4 channel mode (8 bit RGBWW)
  • 7 channel mode (Ape Labs mode)
  • 128 channel 32-pixel mode (RGBWW)
  • 32 channel 8-pixel mode (RGBWW)
• Radio/ Wireless
  • 2,4 GHz (2.400 – 2.485 MHz)
  • Max. 20 dBm (~100 mW, EIRP*)
• Housing
  • Weatherproof – suitable for indoor & outdoor use
  • 2 neodymium magnets with screw thread (removable)
  • Tube diameter: 4 cm (polycarbonate profile)
  • End caps made of aluminum
  • Tube material: polycarbonate
  • Including ring eyelet made of VA (stainless steel)
• Other functions
  • Music Mode (Sound-to-Light)
  • Flexibility in color, brightness, effects and programs
  • PWM (LED Refresh Rate) adjustable between 500 Hz and 4000 Hz
  • Pairing function for stable and secure wireless connection of all Ape Labs devices
  • Cloud-based storage of lamp settings on all devices simultaneously
  • Free software updates for lamps, CONNECT and apps
  • Regular new functions & features through Ape Labs community updates
• Light Properties
  • LED type: RGB WW
  • Lamp: 96 x LED pixels (multipixel controllable)
  • Wavelength Red: 622,5 nm
  • Wavelength Green: 522,5 nm
  • Wavelength Blue: 462,5 nm
  • Color temperature warm white: 2700 K
  • Colour rendering in CRI (Ra): 90
  • PWM (pulse width modulation): >2 kHz
  • Flicker free: Ja
  • Dimmable: Ja
  • Luminous flux (in lumens): 750
  • Lamp luminous flux warm white: 750
  • Lamp luminous flux red: -
  • Lamp luminous flux green: -
  • Lamp luminous flux blue: -
• Material: Made of aluminum and polycarbonate
• Dimensions: 39.37 x 1.56 inch (100 x 4 cm)
• Weight: 2.65 lbs (1.2 kg)

What's in the Box

• 1x Neon Pix w/ Magnets
• 1x M6 Safety Eyelet

Note: Controller and charger not included
