ChamSys QuickQ DIN

About: ChamSys QuickQ DIN

The intuitive simplicity of QuickQ software in a space-saving DIN rail mount solution.

QuickQ DIN supports all QuickQ features including Events, 10Scene and Executes, making it ideal for any installation where space is at a premium and control in a small package is required.

Control up to 4 universes from the device via Art-Net or sACN, the QuickQ DIN also features two RDM-enabled DMX outputs. Easily build installed lighting control systems with connectivity features that include inbuilt Wi-Fi for programming and remote control, and four 10Scene ports for connecting up to forty 10Scene wall plates.

• Ideal for installations and architectural settings
• Featuring four Universes of DMX output
• Two RDM enabled DMX outputs
• Inbuilt Wi-Fi for programming and remote control
• Four 10Scene ports for connection of up to forty 10Scene wall plate
• Features the same intuitive software as QuickQ Consoles
• Simple Hot-Takeover mode allowing an external console to take control

Specifications

• Hardware
  • Universes supported: 4
  • Direct DMX Outputs Pheonix Screw Terminal: 2
  • External Monitor: 1920 x 1080 HDMI
  • Inbuilt Wi-Fi: Yes
  • Network Port: 1
  • USB Ports: 2
  • Power Input: 12v DC
• Software
  • Max Number of DMX Channels: 2048
  • Max Number of Fixtures Supported: 2048
  • OSC Supported: Yes
  • RDM Autopatch for fast show patching
  • Fixture library of over 48,000 fixture files
  • Built in FX generator
  • Colour picker and Gel inbuilt Gel library
  • RDM Autopatch for fast show patching
  • Offline designer software available for Windows and Mac
  • Supported fixtures: All - LEDs, Dimmers & Moving Lights
• Weights and Dimensions:
  • Width : 200mm (7.8 inches)
  • Depth: 165mm (6.5 inches)
  • Height: 40mm (1.6 inches)
  • Weight: 0.65kg (1.43lb)

Included Accessories

1x Wi-Fi Antenna
2x DIN Rail Mount Clips
4x 10Scene Connectors
1x 12v Power Supply
