OM System M.Zuiko Digital ED 100-400mm F5.0-6.3 IS II Lens

About: OM System M.Zuiko Digital ED 100-400mm F5.0-6.3 IS II Lens

A compact lens with so much telephoto reach shouldn’t be possible. Yet here it exists, and you’ll love the freedom that comes with it. Packing a 35mm equivalent focal range of 200mm to 800mm in a lightweight weathersealed design, it’s an ideal lens for wildlife, motorsports, and telephoto macro shooting.

• Compact Reach. 200-800mm (35mm equiv.) reach in a lightweight 1125g body
  • 200-800mm Focal Length (35mm equivalent)
• Weathersealed. Always ready for any condition, thanks to the IPX1-certified weather sealing
  • IPX1 certified weathersealing
• Sync IS up to 7.0 stops EV. Unmatched stability while shooting handheld with long focal lengths.
  • Up to 7.0 stops EV Sync-IS
• Up to 1600mm with MC-20 Teleconverter (35mm equivalent)
• 1.3 m closest focus distance
• Up to 0.57 image magnification

Lightweight design, heavyweight reach

Looking for an ideal focal length range and outstanding performance, including excellent close-focus capability? Look no further. This lens is perfect for capturing flocks of birds, detailed close-ups of wildlife and insects, and a variety of natural habitats.

• Reach up to 800mm: In bird and wildlife photography, reach is essential. Starting at 400mm to capture subjects from a distance in their natural habitats, and extending to 800mm for detailed portraits (35mm equivalent), all while avoiding disturbance to the animals.
• Extend to 1600mm: This lens is compatible with teleconverters, offering super telephoto shooting up to 1600mm (35mm equivalent) with the M.Zuiko Digital 2x Teleconverter MC-20. Perfect for capturing distant wildlife without disturbance, it’s also compatible with the M.Zuiko Digital 1.4x Teleconverter MC-14.
• Tele + Macro = Telemacro: Featuring a 1.3-meter minimum focusing distance, this lens allows telemacro shooting with 0.57x magnification (35mm equivalent). Ideal for photographing insects like butterflies, it also supports Focus Stacking on compatible OM SYSTEM cameras for sharp images with enhanced depth of field.

Say goodbye to blur and shake.

Easily go to the locations with the best shots. The M.Zuiko 100-400mm IS II’ built-in image stabilization frees you to shoot handheld. The sophisticated stabilization works with any camera body to help compensate for hand shake, producing sharp shots from any angle.

• 5-Axis sync IS up to 7.0 stops EV: A new addition to this lens is the 5-axis sync IS, offering stabilisation of up to 7.0 stops EV when paired with compatible OM SYSTEM camera bodies. This cutting-edge feature guarantees stability and reliable performance, even in demanding shooting conditions.
• Experience handheld stability: The compact, lightweight design makes traveling to photo locations easier, reducing your load while searching for birds and wildlife. Smooth handheld shooting without a tripod or monopod lets you capture panning shots of moving subjects, whether in flight or on the move.
• Versatile Tripod Mount Design: A new, lightweight tripod mount design allows it to be detached even when the lens is attached to the camera. The tripod mount foot is compatible with Arca-Swiss type clamps, and its shape is optimized for easy carrying when held by the mount.

Worry-free weather sealing

When photographing in the wild, weather conditions can be unpredictable. Certified weather sealing eliminates the need for rain covers, keeping your equipment dry so you can focus on capturing the shot.

• IPX1 certified weathersealing: Hermetic sealing of the entire lens provides IPX1 splashproof protection and a dustproof design. This construction prevents dust and moisture from entering, giving you peace of mind when shooting in harsh environments.
• Fluorine coating: The front lens is coated with fluorine for added protection. In rainy, snowy, or dusty conditions, the lens can be easily cleaned with a blower or lens cloth, allowing for continued photographing without interruption.

Specifications

• Product Type: Micro Four Thirds Interchangeable Lens System Camera Compatible
• Focal Length: 100-400mm
• 35mm Equivalent Focal Length: 200-800mm
• Lens Construction: 21 elements in 15 groups (4 ED lenses, 2 Super HR lenses, 2 HR lenses); ZERO coating an Flourine Protective Coating
• Weather Resistant Construction: IEC Standard publication 60529 IPX1 (applicable when the lens is used with OM SYSTEM weather-sealed body)
• Angle of View: 12 degrees - 3.1 degrees
• Closest Focusing Distance: 0.25m
• Maximum Image Magnification: 0.08x
• 35mm Equivalent Maximum Image Magnification: 0.16x
• Minimum Field Size: 216 x 162mm
• Number of Blades: 7 (circular aperture diaphragm)
• Maximum Aperture: F1.8
• Minimum Aperture: F22
  • When paired with M.ZUIKO DIGITAL 1.4x Teleconverter MC-14
    • Maximum Image Magnification: 0.12x (f:140mm) / 0.40x (f:560mm)
    • 35mm Equivalent Maximum Image Magnification: 0.24x (f:140mm) / 0.81x (f:560mm)
    • Minimum Field Size: 143.5×107.9mm (f:140mm) / 42.8×32.1mm (f:560mm)
    • Maximum Aperture: F7.1 (f:140mm) to F9.0 (f:560mm)
    • Minimum Aperture: F22
  • When paired with M.ZUIKO DIGITAL 2.0x Teleconverter MC-20
    • Maximum Image Magnification: 0.17x (f:200mm) / 0.57x (f:800mm)
    • 35mm Equivalent Maximum Image Magnification: 0.34x (f:200mm) / 1.15x (f:800mm)
    • Minimum Field Size: 101.2×76.0mm (f:200mm) / 30.1×22.6mm (f:800mm)
    • Maximum Aperture: F10 (f:200mm) to F13 (f:800mm)
    • Minimum Aperture: F22
• Lens IS Mechanism: VCM
• IS Performance
  • ​5-axis sync IS  7.0 steps (f:100mm) /5.5 steps (f:400mm)*
    • * According to CIPA standards. When attached to OM-1 Mark II, with yaw and pitch applied to camera, half-press IS set to Off.
  • Lens IS  4.5 steps (f:100mm) /4.5 steps (f:400mm)*
    • * According to CIPA standards. When attached to E-M10 Mark IV, with yaw and pitch applied to camera, half-press IS set to Off.
• Filter Size: Diameter 72 mm
• Dimensions: Φ86.4 x 205.6mm
• Weight
  • 1,125g (without tripod adapter, lens cap, lens rear cap and lens hood)
  • 1,300g (with tripod adapter, without lens cap, lens rear cap, and lens hood)​

What's in the Box

• LH-76D Lens Hood
• LC-72D Lens Cap
• LR-2 Lens Rear Cap
• Instruction Manual
• Warranty Card
