Prolights EclPar IPMFC 100W IP65 RGB+WW Single Source LED PAR

About: Prolights EclPar IPMFC 100W IP65 RGB+WW Single Source LED PAR

EclPar IPMFC is a flexible IP rated single source LED spotlight, featuring an 100W RGB+WarmWhite light source with high efficiency and advanced colour control.

Its Spektra calibrated LED source delivers a high-quality white reproduction with high CRI and TM30 with an advanced control over colours, ensuring consistency across fixtures.

The unit is compact and completely fan free, making the EclPar IPMFC a workhorse for any outdoor and dusty environment, corporate events or studios where silent operations are required.

The flexible optical system allow a wide selection of lenses from narrow 15° (on board), flood 30°, and ultra wide 60°, which can be quickly mounted in front of the luminaire or inside the front tempered glass for lasting exterior installation.

Features

• 100W Spektra calibrated RGB + Warm White LED delivering high CRI, TLCI, TM30 values
• Flex lens system: 15° on-board - 30° and 60° optional
• IP65 for exterior application, fan free

Specifications

• LIGHT SOURCE
  • Source:100 W RGB+WW LED array
  • Luminous flux:(15°) 3’324 lm; (30°) 3’348 lm; (60°) 3’462 lm @full
  • Lux:(15°) 1’772 lx; (30°) 332 lx; (60°) 155 lx @5 m full
  • CRI:93,7 @3’200K; 91,1 @5’600K
  • R9:89 @3’200K; 88 @5’600K
  • TLCI:77 @3’200K; 86 @5’600K
  • TM30 Rf:90 @3’200K; 89 @5’600K
  • TM30 Rg:109 @3’200K; 108 @5’600K
  • Source life expectancy: > 50.000 h
• OPTICS
  • Beam angle:(on-board) 15° - (opt) 30°, 60°
  • Field angle:(on-board) 26 °
  • Lens diameter:172 mm
  • Lens type: parabolic reflector in combination with HD fresnel lens
  • Additional optics:(opt) 30°, 60°
  • Other: possible to mount lens both on the internal side and on the external side
• COLOUR SYSTEM
  • Colour mixing: RGB + Warm White
  • CCT: CCT control, + / - green correction, tungsten emulation
  • White presets:2.700 K ~ 10.000 K
  • Macros: Gels library on-board
• DYNAMIC EFFECTS
  • Static mode: selection of static dimmer, colors and color temperature
  • Manual mode: manual adjustment of colour
  • Auto mode: built-in programs with execution speed adjustment
  • Special features: linear crossfade channel from any white to any colour; virtual CTO on colours
• BODY
  • Body: sturdy die-cast aluminium body
  • Body colour: black
  • Other:Front mount holder for accessories as barn door, filter frame
• CONTROL
  • Protocols: DMX512, RDM, CRMX
  • DMX channels:1 / 2 / 5 / 9 / 10 / 12 / 18 channel
  • Wireless Control: optional, LumenRadio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX)
  • RDM: RDM for remote monitoring and settings
  • Display: Graphic User Interface
  • Firmware upgrade: yes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included
  • Master/Slave: for synchronised operation of more units linked in a chain
• ELECTRONICS
  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves:4 selectable dimming modes available
  • Strobe / shutter:1 - 30 Hz, electronic
  • Operating temperature: -20° C / +45° C (-4° F / +113° F)
  • LED Control: flicker free operation
  • Selectable PWM: 600 ~ 40.000 Hz
• ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Max power consumption: 120W
  • Output (at 230V): 14 units on a single power line
  • Power factor: > 0,94
  • Inrush current: 110VAC/8.0A, 230VAC/18.9A
• PHYSICAL
  • IP rating: 65 for temporary outdoor application, not for fixed installations
  • Cooling: passive cooling and fan-free
  • Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
  • Signal connection: Seetronic XLR 5p IN/OUT connectors
  • Power connection: Seetronic powerCON TRUE IP65 IN/OUT
  • Dimensions (WxHxD):262x327x213 mm
  • Weight:4,1 kg
• CERTIFICATIONS / APPROVALS
  • Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC
    • (*) NOTE: Suitable for permanent outdoor use, provided installation and maintenance cycles by qualified technicians are carried.

What's in the Box

• 1x ECLPARIPMFC
• 1x EPIPMLENS15
• 1x ECLPARTPG
• 1x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector)
• 1x User Manual
